K-TRON K-Vision User Manual

1 Programming Reference
1.8 I/O Menu
Page 52 Docu-No.: 0590020601-EN Rev. 1.6.0
1.8.4 Analog output sub-menu
• The KCM CPU only outputs a 0-20 mA current value. Use
appropriate resistors to convert to the desired voltage.
• Maximum source voltage is 12 Vdc for the current output.
• For calibration, see section 3.2.
Refer to KCM Electronics manual for more information on electrical
connections and operational limitations.
Parameter
Definition
AOUT NUM
Analog Output
Selection of the desired analog output for the KCM.
Select: CPU, EXT1 - EXT3.
Input range: See list
Note:
For Ext1-Ext3 functions to work, Modbus I-O must be configured first
and the external I-O module (e.g.WAGO) connected via K-Port 2.
FUNCTION
Analog Output Function
The analog output can be assign with the following function:
SETPOINT (20mA/Max. setpoint) x Actual setpoint
MASSFLOW (20mA/Max. setpoint) x Massflow
NETWEIGHT (20mA/Scale range) x net weight
DRIVE COMMAND (20mA/100%) x Percent drive command
MOTOR SPEED (20mA/
Max Mot RPM) x Act Mot Spd
FEEDFACTOR (12mA/Init FeedFactor) x actual feedfactor)
Input range: See list Default: None
AOUT VALUE%]
Analog Output Value%
Display of the actual output value in percentage of the maximum
value.
Input range: Display only
AOUT MIN
Analog Output Minimum
Scaling of the analog output for the minimum value. (Offset
adjustment e.g. 20% for 4 mA)
This value can be used also to invert the analog output.
Input range: 0 to *100% (*Inverted 100%)
AOUT MAX.
Analog Output Maximum
Scaling of the analog output for the maximum value.
This value can be used also to invert the analog output.
Input range: 100 to *0% Default: 100% (*Inverted 0%)
DEABAND-[%]
Analog Output Deadband
Input of the deadband in percentage of the maximum value.
Changes at the output below this value will have no change to the
process value.
Input range: 0 to 100% Default: 0%
