Docu-No.: 0590020601-EN Rev. 1.6.0 Page 55
Programming Reference 1
Loader menu 1.9
1.9 Loader menu
This menu programs the vacuum loader function. No HCU is required.
See section 5.2 for more information on loader applications.
Notes:
• In later KCM S/W versions 1.3 and later, this menu will be hidden if
an HCU is connected to the KCM.
• Be sure the parameter <LOADER FUNCTION> in this menu is
<Disabled> if a loader with HCU control is to be used.
1.9.1 Loader parameters
Parameter
Definition
LOADER FUNCTION
Loader Function
Selects whether loader runs or not. Select <KCM IO> or
<EXTERNAL> to run, <OFF> to stop.
MAX LOAD TIME
Max Load Time
Load time in seconds to reach the high level proximity sensor. An
alarm will occur if the high level is not reached in this time.
Default: 30 seconds
SHUTDOWN TIME
Shutdown Time
Time, in seconds, for the motor to wind down at the end of the load
cycle.
Default: 5 seconds
DISCHARGE TIME
Discharge Time
Time, in seconds, it takes to discharge the loader contents.
Default: 10 seconds
VALVE CLOSE TIME
Valve Close Time
Time, in seconds, it takes for the discharge valve to close at the end
of a discharge.
Default: 5 seconds
