1
Programming Reference
1.2
Ca
libration
Page 20
Docu-No.: 0590020601-EN Rev. 1.6.0
1.2.3
Feedfactors sub-menu for vibratory
feeders
Parameter
Definition
MF @ 8% DC
V
ibratory FF 8%
MF @ 12% DC
V
ibratory FF 12%
MF @ 17% DC
V
ibratory FF 17%
MF @ 23% DC
V
ibratory FF 23%
MF @ 33% DC
V
ibratory FF 33%
MF @ 50% DC
V
ibratory FF 50%
MF @ 70% DC
V
ibratory FF 70%
MF @ 100% DC
V
ibratory FF 100%
These individual values are calculated auto
matically by the function
<AUTO FF CALIB>.
When the setpoint change exceeds the <SEPT CHG LIM>, the
controller switches to using the a
ppropriate MF value at the Drive
Command expected.
19
21
Table of Contents
Default Chapter
3
Table of Contents
3
Additional Programming Information
7
Manual Notation
8
Abbreviations and Terminology
9
Menu and Sub-Menu Listing
10
Product Change Menu
11
Product Change Parameters
11
Calibration
16
Calibration Sub-Menu
16
Feedfactors Sub-Menu for Motor Driven Feeders
19
Feedfactors Sub-Menu for Vibratory Feeders
20
Alarm Menu
21
Limits Sub-Menu
21
Alarm Setup Sub-Menu
23
Tuning Menu
25
Tuning Parameters
25
Method Selection Versus Tuning Parameters Table
27
Refill Menu
28
Scale Menu
30
General Sub-Menu
30
SFT Sub-Menu
31
Manual Addressing of Sfts
33
Machine Setup Menu
34
General Sub-Menu
34
Changing Feeder Control Application Type
35
KSU-II/KCM Screen Saver Description
36
Motor Sub-Menu
37
Motor Sub-Menu for DC Motor
37
Motor Sub-Menu for AC Interface Drive
39
Motor Sub-Menu for Vibratory Drive
40
Motor Sub-Menu for Universal Stepper Motor
41
Motor Sub-Menu for Hipo, Lopo Stepper Motor
42
Stepper Motor Programming Table
43
Service Sub-Menu
44
Performance Sub-Menu
45
Actiflow Sub-Menu
47
I/O Menu
48
Digital Input Sub-Menu
49
Digital Output Sub-Menu
50
Setpoint Input Sub-Menu
51
Analog Output Sub-Menu
52
Modbus I-O Sub-Menu
53
Adding External Modbus I-O, an Example
54
Loader Menu
55
Loader Parameters
55
HCU / LSR Loader Set-Up
56
System Setup (Only KSU-II/KCM)
58
Communication Sub-Menu
58
SW Version Submenu
59
Drive Type by Displayed MDU
60
Parameter Backup Sub-Menu
61
Changing the K-PROM Password
61
Security Menu (Only KSU-II/KCM)
62
Security Parameters
62
Function Data Lock out
63
2 Calibration
64
3 Other Programming
65
Setting Refill Parameters
65
Setting the Refill Max Value
65
Setting the Refill Min Value
65
Setting the Post Refill Delay
65
Setting the Refill Timer
66
Calibrating Analog I-O
67
Using an External Motor Drive
68
4 Alarm Messages- Cause and Remedy
69
System Alarms
69
LWF Alarms
76
Display Messages
77
Feeder Won't Start - Displayed Messages
77
Feeder Won't Run in GRAV
77
Massflow Variances in LWF Feeding
78
5 Appendix
80
Special KCM LWF Features
80
Automatic Gear Switching for LWF
80
SFT Addressing
82
LWF Tuning for the KCM
83
Pert Values and Control Response
83
Tuning Parameter Descriptions
84
Refill Algorithms for the KCM
85
Refill Using the Integrated Loader Function
88
Programming the Loader Function
93
Programming Parameters for HCU
94
Status Tables
95
DC Drive Hex Status Codes-1600/450 W Drives
95
Vibratory Drive Hex Status Codes
96
Stepper Drive Hex Status Codes for All Types
97
AC Drive Interface Hex Status Codes
98
SFT Status Table
99
Actiflow Drive Hex Status Codes
100
Loading Language File
101
Service Variables
102
LWF PSR Map
104
LWF ASR Map
106
Parameter Listing-LWF
112
