Docu-No.: 0590020601-EN Rev. 1.6.0 Page 69
Alarm Messages- Cause and Remedy 4
System alarms 4.1
4 Alarm Messages- Cause and Remedy
4.1 System alarms
• The associated number is the alarm number used for configuration
and data communication.
• The HCU is the control unit for the Hurricane vacuum material
loader for the feeder. It is programmed via the KSU-II/KCM and its
alarms are reported there.
• The first number is the KCM alarm, the second the HSU alarm.
(KCM#/HSU#). This code begins at KCM alarm (21) and ends at
KCM alarm (29).
Alarm Num- Alarm
Cause Remedy
00 HARDWARE
ERROR
• KCM Hardware error. EEPROM
data is corrupt. For example, this
message will occur after updating or
changing firmware on the KCM.
Check KCM CPU.
Clear alarm and try unit.
01 KPROM MEM
FAIL
• The K-PROM cannot be accessed
by the KCM CPU.
Correctly insert K-PROM.
Replace with known good K-
PROM.
02
KPROM*KGR*FAIL
• Checksum error in kgr file area. Verify K-PROM is properly
installed.
Replace K-PROM.
03 POWER GLITCH • Power dip detected. CPU did not
reset.
Verify AC mains are within
specification.
Replace drive pcb (power supply).
04 KPROM WRITE
COUNT
EXCEEDED
• The K-Prom Write Counter exceeds
100'000 writes
Check communication.
Replace with known good K-
PROM.
05 INT CHAN FAIL • Internal channel has failed to
communicate between the CPU and
drive boards. (also SFTs and HCU)
Check Internal Channel
connections.
Replace either CPU or Drive pcb.
(also check SFTs and HCU if used)
Table page 1 of 7
