1 Programming Reference
1.8 I/O Menu
Page 48 Docu-No.: 0590020601-EN Rev. 1.6.0
1.8 I/O Menu
These menus program the digital and analog I-O functions. The KSL
shows these variables over four pages; Digital Output, Digital Input,
Analog Input, Analog Output. The KSC uses 3 screens.
I/O Definitions:
DENA = drive enable
ALS = alarm shutdown
Inputs with an * are activated by an edge transition. All other inputs
are by level
^ indicates a digital output that can be mapped to DIGOUT MAP
CPU_In1...CPU_In4 are for the programmable digital inputs on the
CPU pcb, terminal block J8
MDU_In1... MDU_In2 are for the programmable digital inputs on the
MDU (Drive) pcb, terminal block J1
CPU_Out1...CPU_Out4 are for the programmable digital outputs
on the CPU pcb, terminal block J8
MDU_Rel1... MDU_Rel3 are for the programmable relay outputs on
the MDU (Drive) pcb, terminal block J5
External_In1...External_In8 and External_Out1...External_Out8
are used for remote MODBUS I-O.
See KCM Electronics manual for wiring details
