K-TRON K-Vision User Manual

5 Appendix
5.4 Status tables
Page 100 Docu-No.: 0590020601-EN Rev. 1.6.0
5.4.6 Actiflow drive hex status codes
Notes:
• Failure modes occur on bits 7 to 15, excluding 9
• These codes are displayed at the KCM interface
Bit Function Hex Code
0 1 = Activator Run. 0 = Stop. 0001
1 1 = safety switch closed. 0 = open. 0002
2 unused 0004
3 1 = Bit 1 Input activated (low level). 0 = not
activated, (high level).
0008
4 1 = Bit 2 Input activated (low level). 0 = not
activated, (high level).
0010
5 unused 0020
6 unused 0040
7 1 = Serial Master Time-out. 0080
8 unused 0100
9 1 = Relay 1 energized. 0 = off. 0200
10 1 = Displacement deviation 0400
11 1 = Current limit/short-circuit 0800
12 1 = Spring failure 1000
13 1 = General drive failure. 2000
14 unused 4000
15 1 = Sensor failure. 8000
