1 Programming Reference
1.7 Machine setup menu
Page 40 Docu-No.: 0590020601-EN Rev. 1.6.0
1.7.7 Motor sub-menu for vibratory drive
Parameter
Definition
KV DEVICE
Vibratory Type
Selection of the used Vibratory type.
KV1=1, KV2=2, KV3=3.
Input range: 1,2,3 Default: KV2=2
VIB SPAN
Vibratory Displacement
Span
Span adjustment for vibratory tray displacement.
The displacement must be measured at the vibratory and the SPAN
calculated according following formula:
NewSpan = OldSpan x ((Expected_Displacement)/(Measured_Displacement))
Input range: 0.5 to 2.0 Default= 1.000
VIB DRIVE%
VIB FREQ Hz
MDU STATUS
MDU Status
The MDU status codes reveal operational condition of the Drive. See
listing of MDU status codes in section 5.4.2.
DC CEILING-[%]
Drive Command Ceiling
Limitation of the drive command output to the vibratory drive.
Input range: 10 to 125% Default: 110%
To Next Page
