1 Programming Reference
1.3 Alarm menu
Page 24 Docu-No.: 0590020601-EN Rev. 1.6.0
STOP BY
Feeder Stopped By
This message displays what caused the KCM to last stop.
Note:
The KSL will display this data on the Alarm Log screen.
• Board reset: KCM CPU was shutdown
• Local display: KSU-II/KCM STOP key pressed
• External display: KSL or KSC STOP key pressed
• ALS Input: Alarm shutdown input caused the stop
• Run DISA: Run Enable input caused the stop
• Stop input: External bit input stop function
• MDU DISA: Drive disabled stopping the output
• Calib: Controller has completed its calibration routine
• Watchdog: an internal timer failure reset the KCM CPU
• Zero SP: The setpoint went to zero while the machine was running
• Emptying: The emptying function, when complete, causes the
KCM drive to stop
• Interlock: The interlock input prevents the KCM from running
Parameter Definition
Table page 2 of 2
