CCC-codes with high resolution and 7 digits
If modules with pulse outputs are selected, high-resolution CCC-codes can reduce the battery lifetime. Please see
paragraph 10.4 re the meter’s battery lifetime.
7 digits CCC-table for MULTICAL

403 (high resolution)
Number of decimals in display
CCC No.
kWh
MWh
GJ
m³
l/h
m³/h
kW
q
p
(m³/h)
Type
403-xXXxxx-xxxxx
484
1 - 3 3 0 - 1 0,6 1x-3x
407
1 - 3 3 0 - 1 1,5 4x-5x-7x-8x-9x
455
1 - 3 2 0 - 1 1,5 4x-5x-7x-8x-9x
454
1 - 3 3 0 - 1 2,5 Ax-Bx
459
1 - 3 2 0 - 1 2,5 Ax-Bx
436
0 3 2 2 0 - 1 3,5 Dx
438
0 3 2 2 0 - 1 6,0 Fx-Gx
483
0 3 2 2 0 - 1 10 Hx-Jx
485
0 3 2 2 0 - 1 15 Kx
CCC-codes with high resolution and 8 digits
8 digits CCC-table for MULTICAL

403 (high resolution)
Number of decimals in display
CCC No.
kWh
MWh
GJ
m³
l/h
m³/h
kW
q
p
(m³/h)
Type
403-xXXxxx-xxxxx
584
1 - 3 3 0 - 1 0,6 1x-3x
507
1 - 3 3 0 - 1 1,5 4x-5x-7x-8x-9x
555
1 - 3 2 0 - 1 1,5 4x-5x-7x-8x-9x
598
1 - 3 3 0 - 1 2,5 Ax-Bx
559
1 - 3 2 0 - 1 2,5 Ax-Bx
The choice of 7 or 8 digits may influence the data communication
If the reading device has been hard coded to a given number of digits for the individual registers, there may occur
errors in the data communication if you select, for example, 8 digits on the meter, while the reading device is hard
coded to, for example, 7 digits.
This type of error most often occurs in systems in which meter and reading device use different communication
types, e.g. a PLC system in which the communication to an M-Bus converter takes place via RS-232 and the
communication to a MULTICAL® meter takes place via M-Bus. In case of suspicion that an error in the data
communication is caused by this, it can be checked by changing the CCC code in MULTICAL® to a variant with
another number of digits but of the same flow meter size.
To change the CCC code, an optical read-out head and METERTOOL are used.
