Kamstrup MULTICAL 403 Technical Description

MULTICAL® 403
22
Kamstrup A/S · Technical description · FILE100000166_B_EN-55121689_M1_07.2023
3.2 Configuration numbers
The software configuration of MULTICAL® 403 is defined on the basis of the configuration number. Below you see an
overview of the meter’s configuration number. Each part of the configuration number is described in more detail in
the following paragraphs.
A
-
B
-
CCC
-
DDD
-
EE
-
FF
-
GG
-
L
-
N
-
PP
-
RR
-
T
-
VVVV
Flow sensor position
Inlet
3
Outlet
4
Measuring unit
GJ
2
kWh
3
MWh
4
Flow sensor coding
(See paragraph 3.2.3)
CCC
Display
(See paragraph 3.2.4)
DDD
Tariffs
No active tariff
00
Power tariff
11
Flow tariff
12
t1-t2 tariff
13
Inlet tariff
14
Outlet tariff
15
Time controlled tariff
19
Heat/cooling volume tariff
20
PQ-tariff
21
Pulse inputs A and B
(See paragraph 3.2.6)
FF
GG
Integration mode
Adaptive mode (4-64 s.) (Display on)
1
Normal mode (32 s.) (Display on)
2
Fast mode (4 s.) (Display on)
3
Adaptive mode (4-64 s.) (Display off)
5
Normal mode (32 s.) (Display off)
6
Fast mode (4 s.) (Display off)
7
Cold water leak detection (inputs A and B)
OFF
0
30 min. without pulses
1
60 min. without pulses
2
120 min. without pulses
3
Pulse Transmitter/Divider
Out-C: V1/4 5 ms
73
Out-C: V1/1 3,9 ms
82
Out-C: V1/4 22 ms
83
Pulse outputs for count registers
E1 and V1 or E3 and V1 32 ms
95
E1 and V1 or E3 and V1 100 ms (0,1 s)
96
Controlled output based on data commands
Controlled output
99
Data logger profile
1
(See paragraph 3.2.10)
RR
Encryption level
Common key
2
Individual key
3
Customer label
(See paragraph 3.2.12)
XXXX
1
For more data logger profiles, see document "Logger profiles and datagrams" at:
www.kamstrup.com/en-en/product-centre

Kamstrup MULTICAL 403 Specifications

General

Type	Ultrasonic Heat Meter
Flow Sensor	Ultrasonic
Pressure Rating	PN16
Battery Life	Up to 16 years
Approval	MID Class 2
Display	LCD
Communication	M-Bus, Wireless M-Bus, Modbus, BACnet
Power Supply	Battery
Accuracy	Class 2
Protection Class	IP54
Housing Material	Composite
Flow Rate Range	0.6 m3/h to 15 m3/h
