Kamstrup MULTICAL 403 Technical Description

MULTICAL® 403
Kamstrup A/S · Technical description · FILE100000166_B_EN-55121689_M1_07.2023
21
Ball valves
Article number
Description
6556-570
½” ball valve with M10 connection for direct temperature sensor
6556-571
¾” ball valve with M10 connection for direct temperature sensor
6556-572
1” ball valve with M10 connection for direct temperature sensor
6556-526
1¼” ball valve with M10 connection for direct temperature sensor
6556-527
1½” ball valve with M10 connection for direct temperature sensor
Gaskets
Article number
Description
2210-131
Gasket for direct short temperature sensor, 1 pc.
2210-061
Gasket for G¾B (R½) flow sensor (thread), 1 pc.
2210-062
Gasket for G1B (R¾) flow sensor (thread), 1 pc.
2210-063
Gasket for G1¼B (R1) flow sensor (thread), 1 pc.
2210-065
Gasket for G2B (R1½) flow sensor (thread), 1 pc.
2210-133
Gasket for DN25 PN25 flow sensor (flange), 1 pc.
2210-132
Gasket for DN40 PN25 flow sensor (flange), 1 pc.
2210-099
Gasket for DN50 PN25 flow sensor (flange), 1 pc.
Safety transformer
Article number
Description
6699-403
230/24 VAC safety transformer 5 VA
6699-404
230/24 VAC safety transformer 10 VA
6699-405
230/12/24 VAC safety transformer 63 VA
Contact Kamstrup A/S for questions about further accessories.

Kamstrup MULTICAL 403 Specifications

General

Type	Ultrasonic Heat Meter
Flow Sensor	Ultrasonic
Pressure Rating	PN16
Battery Life	Up to 16 years
Approval	MID Class 2
Display	LCD
Communication	M-Bus, Wireless M-Bus, Modbus, BACnet
Power Supply	Battery
Accuracy	Class 2
Protection Class	IP54
Housing Material	Composite
Flow Rate Range	0.6 m3/h to 15 m3/h
