MULTICAL® 403
Kamstrup A/S · Technical description · FILE100000166_B_EN-55121689_M1_07.2023
19
The flow sensors are type approved for dynamic ranges q
p
:q
i
= 250:1 and 100:1, but basically 100:1 is supplied.
Please contact Kamstrup A/S for information on the availability of the above MULTICAL® 403 variants on the
individual markets.
3.1.1 Accessories
Supply modules
Article number
Description
HC-993-02 Battery module with one D-cell
HC-993-03 230 VAC High Power supply module
HC-993-04 24 VAC/VDC High Power supply module
HC-993-06 Battery module with one C-cell IoT
HC-993-07
230 VAC supply module
HC-993-08
24 VAC supply module
HC-993-09 Battery module with two A-cells
6699-047 Supply label, 10 pcs. (2006-681)
Various accessories
Article number
Description
3026-517 Sealing cap for sensor, blue, 2 pcs.
3026-518 Sealing cap for sensor, red, 2 pcs.
3026-1330 Sealing cap for DS sensor and R½" nipple, grey, 2 pcs. per sensor
3026-1331 Sealing cap for DS sensor and R¾" nipple, grey, 2 pcs. per sensor
2105-002 Sealing cap G¾B (R½)
3026-1148 Sealing cap self locking G¾B (R½) coupling
3026-655.A Wall bracket including mounting kit
3026-902 Bracket for mounting MULTICAL® 403 on MULTICAL® 402 wall bracket
3026-909 Holder for optical reading head
3026-961 Separation tool base
3026-962 Separation tool bracket
3130-262 Blind plug with o-ring
3130-269 Cable relief set
5000-337 Module cable 2 m (2 x 0,25 mm²)
6699-035 USB cable for module configuration
6699-042 Metal plate for optical reader 20 pcs.
6699-043 Accessory bag with sealing buds
6696-005 Optical read-out head with Bluetooth
6699-099 Optical read-out head with USB plug
6699-447.E Internal antenna for Kamstrup radio, 434 MHz
6699-448 Mini Triangle antenna for Wireless M-Bus and 2G/4G Network Module
6699-482.E Internal antenna for wM-Bus, 868 MHz
