MULTICAL® 403
Kamstrup A/S · Technical description · FILE100000166_B_EN-55121689_M1_07.2023
The pulse duration of the pulse outputs is configured as part of the meter’s configuration number via the PP-code.
Upon receipt of order the PP-code is configured at 95 by default (unless otherwise requested by the customer). The
pulse duration can be configured when submitting the order. Valid PP-codes appear from the table below. The
default code 95 is marked in green. The PP-code can be reconfigured by means of the PC-program METERTOOL
HCW. See “Technical description for METERTOOL HCW (5512-2097)”.
Pulse Transmitter/Divider
Out-C: V1/1 3,9 ms 82
Pulse outputs for count registers
E1 and V1 or E3 and V1 32 ms
E1 and V1 or E3 and V1 100 ms (0,1 s)
Controlled output based on data commands
99
Controlled output
The meter can be configured for data command control of pulse outputs. If controlled output is required, the PP-
code is to be configured at 99. During the configuration connected external equipment can switch the meter’s
outputs C and D OFF (open optotransistor output) and ON (closed optotransistor output) respectively via KMP data
commands.
Output status can be read via the KMP-registers. After a power-on reset the outputs will have the same status as
before the power interruption as every change of status is saved in the meter’s EEPROM.
3.2.10 Data logger profile >RR<
MULTICAL
403 has a permanent memory (EEPROM), in which the results from various data loggers are saved. The
data logger is programmable. The required data logger profile is selected via the RR-code of the configuration
number. Unless otherwise stated by the customer, the RR-code is set at 30, which is the default data logger profile. If
data logging of other registers, different intervals and logging depths are required, data logging profiles can be
composed to match individual requirements. The programmable data logger includes the following six data loggers:
- Yearly logger
- Monthly logger
- Daily logger
- Hourly logger
- Minute logger1
- Minute logger2
If the data logger profile is changed to another profile after commissioning of the meter, the saved logged values are
deleted from the meter.
Data logger registers and logging depth are both programmable, and individual logging profiles can be prepared as
required by the customer. The table on the next page shows an example of a logging profile (RR code = 30), which is
based on but not identical to the logger in MULTICAL® 602.
