Kamstrup MULTICAL 403 Technical Description

MULTICAL® 403
140
Kamstrup A/S · Technical description · FILE100000166_B_EN-55121689_M1_07.2023
Help button
Contact The contact key provides links to Kamstrup's website
and mailbox.
Output This button displays the last used functions of the
program.
User manual Link to the meter’s user manual on Kamstrup's
website
About button
List of LogView's program version and revision numbers as well as all sub-programs of the entire LogView HCW
program, including type numbers and revision numbers.
14.6.1 Application
Double click on link or icon for ”LogView HCW” in order to start the program and select the required data function.
Meter identification! Click on ”Connect”.
”Daily log” is used as an example:
Select required registers by clicking the box beside the register name. In order to read all data, select all values by
clicking “Select all”.
When the reading is complete, you can save the values by clicking “Save”. We recommend that you save the
readings to make sure that the data can be reopened later for further analysis or for documentation purposes.
The values are shown in graphical or tabular form by activating “Graph/Table” (toggle function).
Select data period
from/to (items).
Export of data
read/entered to
Excel spreadsheet.
Click on ”Read” in
order to collect
required data from
the meter.
Select presentation
in graphical or
tabular form of data
from read/entered
period.
Or enter file with
previously saved
logger data.
Select required data
registers.
In order to save the
read values in a
file.

Kamstrup MULTICAL 403 Specifications

General

Type	Ultrasonic Heat Meter
Flow Sensor	Ultrasonic
Pressure Rating	PN16
Battery Life	Up to 16 years
Approval	MID Class 2
Display	LCD
Communication	M-Bus, Wireless M-Bus, Modbus, BACnet
Power Supply	Battery
Accuracy	Class 2
Protection Class	IP54
Housing Material	Composite
Flow Rate Range	0.6 m3/h to 15 m3/h
