MULTICAL® 403
20
Kamstrup A/S · Technical description · FILE100000166_B_EN-55121689_M1_07.2023
Calibration unit
Article number
Description
6699-366
Calibration unit for MC403, Pt500, Heat/Cooling (used with METERTOOL HCW)
6699-367
Calibration unit for MC403, Pt100, Heat/Cooling (used with METERTOOL HCW)
Software
Article number
Description
6699-724 METERTOOL HCW
6699-725 LogView HCW
Couplings
Article number
Description
6561-323
Coupling incl. gasket, DN15, G¾B - R½, 2 pcs
6561-324
Coupling incl. gasket, DN20, G1B - R¾, 2 pcs
6561-349
Coupling incl. gasket, DN25, G1¼B - R1, 2 pcs
6561-350
Coupling incl. gasket, DN32, G1½B - R1¼, 2 pcs
6561-351
Coupling incl. gasket, DN40, G2B - R1½, 2 pcs
Extensions
Article number
Description
1330-010
Extensions excl. gaskets, 110 - 165 mm/165 - 220 mm, G¾B - G1B, 1 item. *
1330-011
Extensions excl. gaskets, 190 - 220 mm, G1B - G1B, 1 pc.
1330-012
Extensions excl. gaskets, 110 - 220 mm, G¾B - G1B, 1 pc. *
1330-013
Extensions excl. gaskets, 110 - 130 mm, G¾B - G1B, 1 pc. *
1330-015
Extensions excl. gaskets, 110 - 130 mm, G¾B - G¾B, 1 pc.
1330-019
Extensions excl. gaskets, 110 - 165 mm, G¾B - G¾B, 1 pc.
* 2 pcs to be ordered per meter
Sensor nipples and pockets
Article number
Description
6556-546
R½ nipple for direct short sensor
6556-547
R¾ nipple for direct short sensor
6557-440
R½ x 65 mm sensor pocket, ø5,8 mm
6557-441
R½ x 90 mm sensor pocket, ø5,8 mm
6557-442
R½ x 140 mm sensor pocket, ø5,8 mm

Kamstrup MULTICAL 403 Specifications

General

Type	Ultrasonic Heat Meter
Flow Sensor	Ultrasonic
Pressure Rating	PN16
Battery Life	Up to 16 years
Approval	MID Class 2
Display	LCD
Communication	M-Bus, Wireless M-Bus, Modbus, BACnet
Power Supply	Battery
Accuracy	Class 2
Protection Class	IP54
Housing Material	Composite
Flow Rate Range	0.6 m3/h to 15 m3/h
