Digital in- and outputs
© KEB, 2012-10 COMBIVERT F5-A, -E, -H Page 7.3 - 27
7
di.11...di.22 (several functions are possible).
di.11...di.22: Input function
Bit Value Explanation Fct. Para
1)
0 1: Fixed value 1
Select xed values
oP.19
1 2: Fixed value 2 oP.20
2 4: increase motorpotentiometer
Motor potentiometer
oP.56
3 8: decrease motorpotentiometer oP.57
4 16: Reset motorpotentiometer oP.58
5 32: forward
Rotation setting
oP.60
6 64: reverse oP.61
7 128: reset error release reset di.09
8 256: Ramp stop stop ramp Pn.23
9 512: DC braking activate DC braking Pn.29
10 1024: Energy saving function Flux reduction uF.08
11 2048: set
Parameter Set Selection
Fr.07
12 4096: Reset to set 0 Fr.11
13 8192: external error Release error state in the inverter Pn.04
14 16384: store AN1
activate save mode for the analog in-
puts
An.03
15 32768: store AN2 An.13
16 65536: store AN3 An.23
17 131072: Start timer 1
Start / stop timer
LE.17
18 262144: Reset timer 1 LE.19
19 524288: Start timer 2 LE.22
20 1048576: Reset timer 2 LE.24
21 2097152: Reset PID controller
PID controller
cn.11
22 4194304: Reset PID (I part) cn.12
23 8388608: Reset PID fade in cn.13
24
16777216: Activation positioning/syn-
chronous
Activae positioning / synchronous mo-
dule
PS.02 *
25 33554432: Slave correction
Correction of the master position
(correction value is added)
PS.03
26 67108864: Reference switch Connection of a reference point switch PS.18
27
134217728: Approach the reference
point
Start approach to reference point PS.19
28 268435456: control GTR7 GTR7 permanent on Pn.64
29 536870912: Start positioning Start positioning PS.29 *
30
1073741824: Slave correction inver-
ted
Correction of the master position
(correction value is subtracted)
PS.10
31 2147483648: I+ function
an additional function ("+" function) is
selected
---
1)
the column „Fct. Para“ indicates the function-related parameter, corresponding to the value in di.11...di.22.
* is scanned with 250µs
