Start-up
© KEB, 2012-10 COMBIVERT F5-A, -E, -H Page 6.2 - 15
6
11. Enterapplicationspecicdata
Application specifc data are e.g.
• limit values (speec limits, torque limits etc.)
⇒ oP Parameter (chapter 7.4 Setpoint limits)
⇒ cS Parameter (chapter 7.8 Torque display and limita-
tion)
•acceleration- / deceleration ramps
⇒ oP Parameter (chapter 7.4 Ramp generator)
• function of the digital in- / outputs
⇒ di Parameter (chapter 7.3 Digital in- and outputs)
• type of speed setpoint setting
⇒ oP Parameter (chapter 7.4) etc.
Proper data for the adaption of the in-
verter to the respective application can
be nd in the corresponding chapters
12. Adjust speed controller
The speed controller parameters can be calculated by the
inverter for applications with constant inertia and rigidly cou-
pled load (see chapter 7.11)
The speed controller must be manually adapted if this ad-
justment is not workable for the application or if the result is
nonsatisfying.
The maximum voltage controller must be parameterized if
the eld weakening range is used.
Note:
Current and ux controller are automa-
tically adjusted during identication.
13. Test run
Check whether the drive operates stable in all speed ranges
and under all load conditions.
In some cases operation with ASCL at low speed is critical. If
the behaviour of the drive (e.g. when reversing or stopping)
is not optimal, additional measures must be executed (de-
scribed in chapter 7.6 "operation at low speed").
If error messages occur during the start-up phase, read chapter 8 „Fault diagnosis“.
6.2.2 Start-up of a synchronous motor
The following chapter describes the initial start-up of a synchronous motor splitted in speed controlled systems
with encoder feedback (F5A-S) and speed controlled systems without encoder feedback (F5E-S).
