In case an invalid parameter address is selected, message "IdAtA" (or "data invalid" via COMBIVIS) is output
and the setting is ignored.
Analog parameter setting offset (An.55)
Denes the parameter value, that adjusts itself at 0 % analog parameter setting. The parameter value must be
entered with the internal standardization of the target parameter.
Desired value of target parameter

Resolution of target parameter
Value to be adjusted =
Analog parameter setting max. value (An.56)
Denes the parameter value, that adjusts itself at 100 % analog parameter setting. The parameter value must
be entered with the internal standardization of the target parameter.
Analog parameter setting set pointer (An.57)
An.57 determines the parameter set which edited the selected parameter. If a programmable parameter is ad-
justed as target parameter, the adjusted set in An.57 is edited.
An.57: Analog parameter setting set pointer
Value Function
-1 active set is edited
0...7 adjusted set is edited
If a non-programmable parameter is adjusted as target parameter, it is always edited in set 0 independent on
An.57.
7.15.9 Register function
It is possible in synchronous operation that master and slave are additionally synchronized to two reference
signals. This reference signals are e.g. in form of approximation initiators at the master and slave axis. The gear
factor is adapted by the register function in order to adjust the time per cycle. Dependent on parameter „pos/syn
mode “ps.00 bit11 it can be adjusted if the gear change is executed in consideration of the ramp times (op.28…
33). An adjustable angle deviation can be used to synchronize the two reference signals.
