KEB COMBIVERT F5-A User Manual

Page 7.1 - 16 COMBIVERT F5-A, -E, -H © KEB, 2012-10
Operating and appliance data
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.91 Energy over gtr 7 025Bh
appl np - 0 99999 1 kW 0
The energy which is converted via the GTR7 resistor is displayed in parameter ru.91.On reaching the maxi-
mum value of 99999 kWh the counter is limited to this value. The limitation is given by the operator display
(5 digits). Parameter ru. 91 is writable. It is set to its default value by new-initialization and writing on power
on counter (ru.40).
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.92 Input power 025Ch RO - - -10000.00 10000.00 0.01 kW 0
The input power is displayed in ru.92.
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.93 Power loss 025Dh RO - - -10000.00 10000.00 0.01 kW 0
The power loss is displayed in ru.93.
7.1.6 Description of the In-Parameters
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
In.00 Inverter type 0E00h
Bit Description Meaning
0
Unit size
0
1
binary coded, e.g. 00101 for size 05
2
3
4
5 Voltage class 0
230 V 1 400 V
6 Power phases 0 single phase 1 3-phase
7 free 0
8
Housing size
0 A housing 6 G housing 20 U housing
9 1 B-housing 7 H housing 22 W housing
10 2 C housing 10 K housing
11 3 D housing 15 P housing
12 4 E housing 17 R housing
13
Control type
0 G control 3 S control 6 R control
14 1 M control 4 A control
15 2 B control 5 C control
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
In.01 Inverter rated current 0E01h RO - - LTK 710 0.1 A -
Display of the inverter rated current in A. The value is determined from the power circuit identication (P-ID)
and cannot be changed.
