KEB COMBIVERT F5-A User Manual

Parameter
© KEB, 2012-10 COMBIVERT F5-A, -E, -H Page 11.1 - 5
10
11
11.1.3 Parameter list F5-A, -E and -H
Legend
Parameter: Parameter group, number and name (ordered by parameter group and number)
Addr.: Parameter address in hex
R: Password level appl => application, ro => read only
P: p => set-programmable; np => not set-programmable
E: E => Enter-Parameter
Lower limit: Min. value (normalized); the non-normalized value results on division by the step range
Upper limit: Max. value (normalized); the non-normalized value results on division by the step range
Step: Step size, resolution
Default: Default value (normalized); the non-normalized value results on division by the step range
LTK => the default value is dependent on the power circuit identication
Unit: Unit
Reference: further information to this parameter on stated page (not chapter)
Parameter Addr. R P E Lower limit Upper limit Default Step Unit See on page
AA.16 Speed diff. lter 1210h appl np --- 0: off 1: on 0: off 1 ---
AA.59 modus isd_ref 123Bh appl np --- 0 2 0 1 ---
AA.60 PT1-Tau isd_ref 123Ch appl np --- 0 65535 1024 1 ---
AA.61 appc./act. torq. PT1-time 123Dh appl np --- 0 10 3 1 ---
AA.62 sel. int. data addr. 123Eh appl np --- 0 38 0 1 ---
AA.63 int. Data address 123Fh RO np --- 0 0FFFFh 0 1 hex
AA.64 Actual value PT1 time 1240h appl np --- 0 10 0 1 ---
An.00 AN1 interface selection 0A00h appl np E 0 2 0 1 --- 3.1-3, 7.1-9, 7.2-3, 7.2-4
An.01 AN1 noise lter 0A01h appl np E 0 4 0 1 --- 7.2-3, 7.2-5, 7.3-15, 7.4-5
An.02 AN1 save mode 0A02h appl np E 0 3 0 1 ---
7.2 - 3,7.2 - 5,7.2 - 6,7.3 - 17
An.03 AN1 save trig. inp. sel. 0A03h appl np E 0 4095 0 1 --- 7.2 - 3,7.2 - 6,7.3 - 11
An.04 AN1 zero point hysteresis 0A04h appl np --- -10.0 10.0 0.2 0.1 % 7.2-3, 7.2-7
An.05 AN1 gain 0A05h appl P --- -20.00 20.00 1.00 0.01 --- 7.2-3, 7.2-8, 7.4-5
An.06 AN1 offset X 0A06h appl P --- -100.0 100.0 0.0 0.1 % 7.2-3, 7.2-8, 7.2-9, 7.4-5
An.07 AN1 offset Y 0A07h appl P --- -100.0 100.0 0.0 0.1 % 7.2-3, 7.2-8, 7.2-9, 7.4-5
An.08 AN1 lower limit 0A08h appl P --- -400.0 400.0 -400.0 0.1 % 7.2-3, 7.2-9
An.09 AN1 upper limit 0A09h appl P --- -400.0 400.0 400.0 0.1 % 7.2-3, 7.2-9
An.10 AN2 interface selection 0A0Ah appl np E 0 2 0 1 ---
3.1-3, 7.1-9, 7.1-10, 7.2-
3,7.2-4
An.11
AN2 interference suppressi-
on lter
0A0Bh appl np E 0 4 0 1 --- 7.2-3, 7.8-13, 7.9-3
An.12 AN2 save mode 0A0Ch appl np E 0 3 0 1 --- 7.2-3, 7.2-5, 7.8-13, 7.9-3
An.13 AN2 save trig. inp. sel. 0A0Dh appl np E 0 4095 0 1 ---
7.2 - 3,7.2 - 6,7.3 - 10,7.3 - 11
An.14 AN2 zero point hysteresis 0A0Eh appl np --- -10.0 10.0 0.2 0.1 % 7.2-3, 7.2-7, 7.8-13
An.15 AN2 gain 0A0Fh appl P --- -20.00 20.00 1.00 0.01 --- 7.2-3, 7.2-8, 7.15-17
An.16 AN2 offset X 0A10h appl P --- -100.0 100.0 0.0 0.1 % 7.2-3, 7.2-8, 7.15-17
An.17 AN2 offset Y 0A11h appl P --- -100.0 100.0 0.0 0.1 %
7.2-3, 7.2-8, 7.8-13, 7.9-3,
7.15-17
An.18 AN2 lower limit 0A12h appl P --- -400.0 400.0 0.0 0.1 % 7.2-3, 7.2-9, 7.15-17
An.19 AN2 upper limit 0A13h appl P --- -400.0 400.0 400.0 0.1 % 7.2-3, 7.2-9, 7.15-17
An.20 AN3 interface selection 0A14h appl np E 0 1 0 1 --- 7.2-3, 7.2-5
An.21 AN3 noise lter 0A15h appl np E 0 4 0 1 --- 7.2-3, 7.2-5
An.22 AN3 save mode 0A16h appl np E 0 3 0 1 --- 7.2-3
An.23 AN3 save trig. inp. sel. 0A17h appl np E 0 4095 0 1 ---
7.2 - 3,7.2 - 6,7.3 - 10,7.3 - 11
An.24 AN3 zero point hysteresis 0A18h appl np --- -10.0 10.0 0.0 0.1 % 7.2-3, 7.2-7
An.25 AN3 amplication 0A19h appl P --- -20.00 20.00 1.00 0.01 --- 7.2-3, 7.2-8
An.26 AN3 offset X 0A1Ah appl P --- -100.0 100.0 0.0 0.1 % 7.2-3, 7.2-8
An.27 AN3 offset Y 0A1Bh appl P --- -100.0 100.0 0.0 0.1 % 7.2-3, 7.2-8
An.28 AN3 lower limit 0A1Ch appl P --- -400.0 400.0 -400.0 0.1 % 7.2-3, 7.2-9
An.29 AN3 upper limit 0A1Dh appl P --- -400.0 400.0 400.0 0.1 % 7.2-3, 7.2-9, 7.2-10
An.30 Sel. REF input./AUX function 0A1Eh appl P E 0 16383 2112 1 ---
3.1-4, 7.1-12, 7.2-3, 7.2-
10, 7.4-4, 7.8-13, 7.9-3,
7.15-30
An.31 ANOUT1 function 0A1Fh appl P E 0 29 2 1 ---
3.1 - 3,7.2 - 11,7.2 - 13,7.12
- 70,7.15 - 31
An.32 ANOUT1 value 0A20h appl P --- -100.0 100.0 0.0 0.1 %
7.2-11, 7.2-13, 7.2-15,7.15-
22
further on next side
