Page 7.3 - 36 COMBIVERT F5-A, -E, -H © KEB, 2012-10
Digital in- and outputs
do.00...do.07: Switching conditions
Va-
lue
Function Description
59 Inputs AND linked (ru.22)
Function Switching condition met if:
AND all selected inputs are active
or at least one of selected inputs is active
NAND at least one of selected inputs is not active
NOR all selected inputs are not active
The selection of inputs to be linked occurs via the comparison level parame-
ters LE.00...LE.07.
Input ST RST F R I1 I2 I3 I4 IA IB IC ID
Value 1 2 4 8 16 32 64 128 256 512 1024 2048
The sum of the inputs to be queried is entered in the switching levels.
Example: If R and I1 shall be linked for condition 0 F, value 4 + 8 + 16 = 28.00
must be entered in LE.00.
60 Inputs OR linked (ru.22)
61 Inputs NAND linked (ru.22)
62 Inputs NOR linked (ru.22)
63
Absolut value ANOUT1 > swit-
ching level
Amount of ANOUT1 (amount of ru.34 „ANOUT1 post ampl. display) or AN-
OUT 2 (amount of ru.36 „ANOUT2 post ampl. display) higher than the swit-
ching level
64
Absolut value ANOUT2 > swit-
ching level
65 ANOUT1 > Level
ANOUT1 (ru.34 „ANOUT1 post ampl. display) or ANOUT 2 (ru.36 „ANOUT2
post ampl. display) higher than the switching level
66 ANOUT2 > Level
67 Distance > level (Posi)
Distance since the last "start positioning" command is longer than the adju-
sted level. If the positioning is completed, the output is reset.
68
Position to the target window >
level (Posi)
The output is set, if the distance to be covered to the target is larger than the
adjusted level.
69
ext. PID system deviation > le-
vel
Amount of the system deviation of the external PID controller> switching
level
70 Driver voltage active
For inverters with safety relay: The driver voltage for control of the power
module is active.
71 Drive runs synchronously
Synchronization phase after activation of synchronous running completed
(nodisplay that there is angle-synchronization between slave and master)
72 Actual position index = level
ru. 60 „actual position index“ is equal to the switching level (scaling factor:
values of 0.51...1.5 count as index 1 etc.)
73 Amount active power > level Amount ru.81 „active power“ > switching level
74 Active power > level ru.81 „active power“ > switching level
75
Amount act. position – scan po-
sition > level
ru.54 „actual position“ – ru.71 „teach/scan position display“ > switching level
76 reserved
77
act. position = position index
PS.28
ru.60 „actual position index“ = PS.28 „start index new prole“ and target win-
dow of this positioning reached
78 Rotary table reference invalid
At ying referencing in a rotary table application a reference signal is reco-
gnized outside the position window of +/- PS.40 „refpoint window“.
