Digital in- and outputs
© KEB, 2012-10 COMBIVERT F5-A, -E, -H Page 7.3 - 43
7
Select switching conditions
Adjust do.16 to „1“ (evaluate switching condition of do.0 ),
Adjust do.17 to „2“ (evaluate switching condition of do.1),
Adjust do.18 to „4“ (evaluate switching condition of do.2),
Adjust do.8, do.9 and do.10 to „0“ (no inversion).
The adjustment of do.24 is independent for this example, as only one condition each is adjusted at do.16...18.
Adjustags
Output O1 (terminal X2A.18)
Set do.33 to „7“(evaluate ags 1...3)
Adjust do.25 to „1“(ag 1 is inverted, it means that the condition is fullled if the inverter does not accelerate).
Adjust do.41 to „1“ (the ags selected with do.33 are AND connected)
Output O2 (terminal X2A.19)
Adjust do.34 to „1“ (ag 1 is evaluated).
Adjust do.26 to „0“ (no inversion)
The adjustment of do.41 is independent for this example, since only one ag is adjusted in do.34.
Relay output R1 (terminal X2A.24...26)
Adjust do.35 to „2“(ag 2 is evaluated).
do.27 to „0“ (no inversion)
The adjustment of do.41 is independent for this example, since only one ag is adjusted in do.35.
Relay output R2 (terminal X2A.27...29)
Adjust do.36 to „4"(ag 3 is evaluated).
do.28 to „0“ (no inversion)
The adjustment of do.41 is independent for this example, since only one ag is adjusted in do.36.
