KEB COMBIVERT F5-A User Manual

Motor data and controller adjustments of the asynchronous motor
© KEB, 2012-10 COMBIVERT F5-A, -E, -H Page 7.5 - 33
7
ds.04: Flux / rotor adaption mode
Bit Meaning Value Explanation
3 Maximum voltage controller
see chapter: Torque display and limiting, section: maximum
voltage controller, voltage limit
4 Maximum voltage controller
see chapter: Torque display and limiting, section: maximum
voltage controller, voltage limit
5 Flux / rotor adaption mode
see section: Generally adjustments for operation with motor
model
6 Flux / rotor adaption mode
see section: Generally adjustments for operation with motor
model
7 Wait for magnetisation
see section: Generally adjustments for operation with motor
model
8 Energy saving function (ASM)
0: off
256: on
–
9 Mode always active (ASM)
0: off
512: on
–
Bit 2 determines whether the drive stores the rotor adaption value on modulation switch-off. If memory ist ac-
tivated (memory: yes), the inverter starts with the last value obtained during operation after reactivation of the
modulation. If memory ist deactivated (memory: no), the inverter starts with the value 100%. After"net on",the
inverter always starts with the value 100%.
In parameter ru.59 "factor rotor adaption", the status of the rotor adaption can be read: 100% means that the
drive is working with the identied values. Values unequal 100% mean that the actual rotor resistance is = ru.59
* dr.08 (DASM rotor resistance).
