Posi- and synchronous operating

● by writing a new target position to parameter PS.24 or by set changeover

To start a positioning by writing a new target position or by set changeover, the following adjustments

must be made in PS.00:

PS.00: Posi / synchronous mode

Bit Meaning Value Explanation

Start posi by set

change

0: off

For "start posi by set change = on", every set change automatically

generates a "start positioning" command.

512: on

12 Start posi PS.24

0: off

For "start posi PS.24 = on", a "start positioning" command is generated

each time by writing on parameter PS.24 (independent of the index).

4096: on

To perform a positioning, the inputs wired as limit switches (inputs with functions "forward" and "reverse") must

be active. If the hardware limit switches are not to be used, the protection functions in Pn.07 "limit switch error

response" must be deactivated (value 6: function switched off).

If the target position can still be changed during a running positioning is determined by PS.00 bit 3.
