KEB COMBIVERT F5-A User Manual

Para. Name Value Notice
Parametrisation of the bus-synchronous operation
SY.16
Proc. read data 1
denition
0236h read ru.54 "Actual position"
Sy.17
Proc. read data
1 set
1 Value immaterial since parameter is not set-programmable
SY.18
Proc. read data 2
denition
0033h read SY.51 "status word (low)"
SY.19
Proc. read data
2 set
1 Value immaterial since parameter is not set-programmable
SY.20
Proc. read data 3
denition
-1: off
SY.21
Proc. read data
3 set
1 No third read parameter dened
SY.24
Proc. write data 1
den.
1322h write PS.34 "Contouring mode position"
Sy.25
Proc. write data
1 set
255 Value immaterial since parameter is not set-programmable
SY.26
Proc. write data 2
den.
0303h write oP.03 "reference setting"
SY.27
Proc. write data
2 set
255 The value of oP.03 is stored in all sets
SY.28
Proc. write data 3
den.
0032h write SY.50 "control word (low)"
Sy.29
Proc. write data
3 set
255 Value immaterial since parameter is not set-programmable
SY.08
Bus synchronisa-
tion time
1000 us
Is written via the customer control or the COMBICONTROL
C5
Posi- and synchronous operating
© KEB, 2012-10 COMBIVERT F5-A, -E, -H Page 7.12 - 81
7
