Page 7.13 - 32 COMBIVERT F5-A, -E, -H © KEB, 2012-10
Protective functions
Here is an overview:
Parameter V/F-
characte-
ristic
operation
vector controlled
DASM
vector control-
led DSM
Pn.44 Power off mode yes yes yes
Bit 0, 1, 3, 4, 5 yes yes yes
Bit 2, 8 yes No function No function
Bit 6, 7, 9 yes only values 0 and
192
No function
Pn.45 Power off start voltage yes yes yes
Pn.46 Power off auto st. level yes yes yes
Pn.47 Power off brake torque yes No function yes
Pn.48 Power off restart level yes yes yes
Pn.49 Power off start inp. sel.
Pn.50 Power off ref. DC voltage yes No function hidden
Pn.51 Power off KP DC voltage yes yes yes
Pn.52 Power off restart delay yes yes yes
Pn.53 Power off KP yes No function hidden
Pn.54 Power off KI yes No function hidden
Pn.55 Power off KD yes No function hidden
Pn.56 Power off jump factor yes No function hidden
Pn.57 Power off KI DC voltage yes yes yes
Power-Off Mode (Pn.44)
The parameter Power-Off-Mode (Pn.44) switches on the function and determines the basic behaviour:
Pn.44: Power off mode
Bit Meaning Value Explanation
0 Power off / activation
0: off Power-off function deactivated
1: on Power-off function activated
1 Start voltage
0: automatically Auto determination of the start voltage
2: xed level (Pn.45) Preset of start voltage with Pn.45
2
Initial jump (only v/f -cha-
racteristic)
0: from the slip
Determination of the initial jump from
the calculated slip
4: from the load
Determination of the initial jump from
the load factor
