KEB COMBIVERT F5-A User Manual

Page 7.15 - 8 COMBIVERT F5-A, -E, -H © KEB, 2012-10
Special functions
Increase motorpoti
value
Decrease motorpoti
value
⇓ ⇓
oP.56 oP.57
Another input (oP.58) can be used to reset the motorpoti to the adjusted reset value oP.55.
Input table
Bit -No. Decimal
value
Input Terminal
0 1 ST (prog. input „control release/reset“) X2A.16
1 2 RST (prog. input „reset“) X2A.17
2 4 F (prog. input „forward“) X2A.14
3 8 R (prog. input „reverse“) X2A.15
4 16 I1 (prog. input 1) X2A.10
5 32 I2 (prog. input 2) X2A.11
6 64 I3 (prog. input 3) X2A.12
7 128 I4 (prog. input 4) X2A.13
8 256 IA (internal input A) no
9 512 IB (internal input B) no
10 1024 IC (internal input C) no
11 2048 ID (internal input D) no
Motorpoti function (oP.50)
The fundamental function of the motorpoti is dened with oP.50. The parameter is bit-coded.
oP.50: Motorpoti function
Bit Meaning Value Explanation
0
Target set of the
motorpoti value
0: act. set (ru.26)
Motorpoti value is changed in the active parameter set
(display in ru.26). Functions using the motorpoti value
work with the value of the current set.
1: Set 0
Motorpoti value is changed in set 0 Functions using the
motorpoti value work with the value of set 0.
1
Reset at switch
on
0: no reset Motorpoti value remains stored on power off
2: Reset to oP.55
Motorpoti value is written in all sets at power on to the
value of oP.55 "motorpoti reset value"
2
Source of the
ramp time
0: Set 0
The adjustment of the motorpoti value occurs with the va-
lue of oP.59 "motorpoti inc/dec time" from set 0.
4: Act. set (ru.26)
The adjustment of the motorpoti value occurs with the va-
lue of oP.59 "motorpoti inc/dec time" from the active set
