Page 7.16 - 8 COMBIVERT F5-A, -E, -H © KEB, 2012-10

CP-Parameterdenition

unstandardized value = standardized value / resolution

Table 3 Representation (Bit 8...11)

Value Representation

0 0 decimal places

256 1 decimal place

512 2 decimal places

768 3 decimal places

1024 4 decimal places

1280 variable decimal places

1536 Hexadecimal

- free

Example

The actual frequency shall be displayed in CP.1 in rpm. Display standardization from set 4.

ud.15 = 1 ; CP.1

ud.16 = 0203h ; Actual frequency ru.3

ud.17 = 4352 ; Display in the actual set, display norm from set 4

Set 4 ud.18 = 80 ; Conversion from 1/80 Hz into rpm without pole-pair number

Set 4 ud.19 = 60

Set 4 ud.20 = 0 ; ; no Offset

Set 4 ud.21 = 17 ; Unit rpm; direct calculation mode;no decimal place
