KEB COMBIVERT F5-A User Manual

Parameter
© KEB, 2012-10 COMBIVERT F5-A, -E, -H Page 11.1 - 17
10
11
Parameter Addr. R P E Lower limit Upper limit Default Step Unit See on page
Pn.14
warning OH2 stop. modeRe-
sponse
040Eh appl np --- 0 6 6 1 ---
7.3 - 17,7.13 - 8,7.13 - 9,7.1
3 - 11,7.13 - 12,7.13 - 17,7.1
3 - 27,7.13 - 28,7.13 - 29,7.
13 - 30
Pn.15 OH2 warning levellevel 040Fh appl np --- 0 100 100 1 % 7.3-17, 7.13-9, 7.13-30
Pn.16 warning OHI stop. mode 0410h appl np --- 0 7 7 1 ---
7.3 - 17,7.13 - 6,7.13 - 11,7.1
3 - 12,7.13 - 13,7.13 - 17
Pn.17 E.OHI delay time 0411h appl np --- 0 120 0 1 s 7.3-17, 7.13-6
Pn.18 E.Set stopping mode 0412h appl np --- 0 6 0 1 ---
7.13-9, 7.13-11, 7.13-12,
7.13-17
Pn.19 stall mode 0413h appl P E 0 255 0 1 --- 7.13-23, 7.13-24, 7.13-25
Pn.20 stall level 0414h appl P --- 0 200: off 200: off 1 % 7.3-17, 7.13-23, 7.13-24
Pn.21
stall acceleration/decelerati-
on time
0415h appl P --- 0 300.00 2.00 0.01 s 5.1-5, 7.13-24, 7.13-25
Pn.22 LAD stop function 0416h appl P E 0 7 0 1 --- 7.13-22, 7.13-23, 7.13-26
Pn.23 LAD stop input selection 0417h appl np E 0 4095 0 1 ---
7.3-10, 7.3-11, 7.13-22,
7.13-23, 7.13-26
Pn.24 LAD load level 0418h appl P --- 0 200 140 1 % 7.3-18, 7.13-22, 7.13-25
Pn.25 LD voltage 0419h appl P --- 200 1200
375 ; 720 ;
1100
1 V
7.3-18, 7.13-22, 7.13-23,
7.13-26
Pn.26 speed search condition 041Ah appl P E 0 31 8 1 --- 7.5-30, 7.6-13, 7.13-21
Pn.27 speed search mode 041Bh appl np E 0 255
88 1 ---
Pn.28 DC braking Mode 041Ch appl P E 0 506 7 1 --- 7.5-30, 7.15-4
Pn.29 DC brake input selection 041Dh appl np E 0 4095 0 1 --- 7.3-10, 7.3-11, 7.15-4
Pn.30 DC braking time 041Eh appl P --- 0.00 100.00 10.00 0.01 s 7.15-4, 7.15-5
Pn.31 DC braking max. voltage 041Fh appl P --- 0.0 25.5 25.5 0.1 % 7.15-5
Pn.32 DC braking start level 0420h appl P --- 0 n * 4000 n * 120
n *
0.125
rpm 5.1-4, 7.15-4, 7.15-5
Pn.33
DC braking maximum current
ASCL
0421h appl P --- 0.0 400.0 100.0 0.1 % 7.5-30, 7.15-5
Pn.34 brake control mode 0422h appl P E 0 4 0 1 ---
Pn.34 brake control mode 0422h appl P E 0 4 2 1 --- 7.6-8, 7.15-13
Pn.35 premagnetizing time 0423h appl P --- 0.00 100.00 0.25 0.01 s
7.6 - 13,7.15 - 14,7.15 - 15,
7.15 - 16,7.15 - 17,7.15 - 18
Pn.36 brake release time 0424h appl P --- 0.00 100.00 0.25 0.01 s
7.3 - 12,7.6 - 13,7.15 - 13,7.
15 - 14,7.15 - 15,7.15 - 17
Pn.37 brake ctrl. start ref. 0425h appl P --- n * -600 n * 600 0
n *
0.125
rpm
5.1 - 4,7.15 - 14,7.15 - 15,7.
15 - 16,7.15 - 17,7.15 - 18
Pn.38 brake fadeout time 0426h appl P --- 0.00 0.50 0.00 0.01 s 7.15-15
Pn.39 brake delay time 0427h appl P --- 0.00 100.00 0.25 0.01 s 7.15-14, 7.15-15, 7.15-18
Pn.40 brake closing time 0428h appl P --- 0.00 100.00 0.25 0.01 s
7.3-12, 7.15-13, 7.15-14,
7.15-15
Pn.41 brake ctrl. stop ref. 0429h appl P --- n * -600 n * 600 0
n *
0.125
rpm
5.1-4, 7.15-15, 7.15-16,
7.15-17
Pn.42 brake check input sel. 042Ah appl np E 0 4095 0 1 --- 7.3-12, 7.15-14
Pn.43 min. load brake ctrl. 042Bh appl P --- 0: off 100 0: off 1 % 7.15-13, 7.15-14, 8.1-5
Pn.44 power off mode 042Ch appl np E 0 1023 0 1 ---
7.13 - 31,7.13 - 32,7.13 - 33,
7.13 - 34,7.13 - 35,7.13 - 36,
7.13 - 37,7.13 - 38
Pn.45 power off start voltage 042Dh appl np --- 200 1200
290 ; 500 ;
860
1 V 7.13-31, 7.13-33
Pn.46 power off auto st. level 042Eh appl np --- 50 90 80 1 %
7.13-31, 7.13-32, 7.13-33
Pn.46 power off auto st. level 042Eh appl np --- 50 100 80 1 %
Pn.47 power off brake torque 042Fh appl np --- 0.0 100.0 0.0 0.1 %
7.13-31, 7.13-32, 7.13-34,
7.13-36, 7.13-37
Pn.48 power off restart level 0430h appl np --- 0 n * 4000 0
n *
0.125
rpm
5.1 - 4,7.13 - 31,7.13 - 32,7.
13 - 34,7.13 - 35,7.13 - 37,7
.13 - 38
Pn.49 power off start input selection 0431h appl np E 0 255 0 1 --- 7.13-31, 7.13-32, 7.13-37
Pn.50 power off ref. DC volt. 0432h appl np --- 200 1200
290 ; 500 ;
860
1 V
7.13 - 31,7.13 - 32,7.13 - 35,
7.13 - 36,7.13 - 37,7.13 - 38
Pn.51 power off KP DC voltage 0433h appl np --- 0 32767 128 1 --- 7.13 - 31,7.13 - 35
Pn.52 power off restart delay 0434h appl np --- 0.00 100.00 0.00 0.01 s
7.13 - 31,7.13 - 32,7.13 - 35,
7.13 - 36,7.13 - 37
Pn.53 power off KP act. curr. 0435h appl np --- 0 32767 800 1 --- 7.13-31, 7.13-35
Pn.54 power off KI act. curr. 0436h appl np --- 0 32767 800 1 --- 7.13-31, 7.13-35
further on next side
