Start-up
© KEB, 2012-10 COMBIVERT F5-A, -E, -H Page 6.2 - 9
6
adjust speed-controlled operation
⇒ cS.00 speed control cong. = 4
(control mode = speed control)
5. Select source of the speed feedback
The motor speed feedback must be connected to Sub-D so-
cket X3A.
⇒ cS.01 actual value source = 0: Channel 1
6. Enter increments per revolution of the speed feedback
Enter the number of increments per revolution according to
the name plate of the encoder
Ec.01 encoder (inc/r) 1
Note: Further adjustments are necessary
when using another encoder type. Read
chapter 7.11 „Speed measurement“
7. Input of the motor data
Values dr.00 to dr.05 must be taken from the motor name
plate.
The values for dr.06 to dr.08 can be taken from the motor
data sheet (if available) or they can be identied automati-
cally (see point 10).
The DASM head-inductance (dr.10) should always be iden-
tied, because it is dependent on the selected magnetizing
current.
⇒ dr.00 DASM rated current
⇒ dr.01 DASM rated speed
⇒ dr.02 DASM rated voltage
⇒ dr.03 DASM rated power
⇒ dr.04 DASM cos phi
⇒ dr.05 DASM rated frequency
⇒ dr.06 DASM stator resistance
⇒ dr.07 DASM sigma-inductance
⇒ dr.08 DASM rotor resistance
⇒ dr.10 DASM head-inductance
Attention: The interconnection of the mo-
tor must be considered at acceptance of
the values of the motor data sheet. The
data sheet contains mostly phase va-
lues. The phase-phase values must be
entered in parameters dr.06...dr.10.
The default values can remain in dr.06 to
dr.10 up to the identication if no equiva-
lent circuit data are known.
8.
Parameterizeux-/rotoradaptationmode
The operation with motor model is activated in parameter
ds.04 ux/rotor adaptation mode.
⇒ dS.04 = 249
Further necessary adjustments for the operation with motor
model are additionally made by this parameter:
• Maximum voltage controller, maximum voltage 100%
(without overmodulation)
• Flux controller and magnetization build-up active before
start-up
Attention: Further adjustments must be
done in connection with the maximum
voltage controller:
Parameterization of the controller 7.9,
Activation of the active current limitation
in the eld-weakening range 7.9.
Further information about the ux con-
troller and ux build-up see chapter 7.6
Adjustments of the synchronous motor
