Page 7.1 - 6 COMBIVERT F5-A, -E, -H © KEB, 2012-10
Operating and appliance data
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.03 actual frequency dis-
play
1)
0203h RO - - -400 400 0.125 Hz -
The displayed actual frequency corresponds to the rotary eld frequency output at the inverter output. The
output is displayed like ru.01.
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.07 actual value display
1)
0207h RO - - -4000 4000 0.125 rpm -
Depending on the adjusted actual source (cS.01) the actual speed of encoder input 1 and/or 2 is displayed.
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.09 Encoder 1 speed
1)
0209h RO - - -4000 4000 0.125 rpm -
ru.10 Encoder 2 speed
1)
0210h RO - - -4000 4000 0.125 rpm -
The displayed speed corresponds to the actual speed measured at the encoder input 1 or 2.
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.11 set torque display 020Bh RO - - -10000 10000 0.01 Nm -
The indicated value corresponds to the current set torque.
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.12 actual torque display 020Ch RO - - -10000 10000 0.01 Nm -
The indicated value corresponds to the actual torque.
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.13 actual utilization 020Dh RO - - 0 65535 1 % -
Display of the current utilization referred to the rated current of the inverter. Only positive values are indicated,
thus it is not possible to differentiate between a motoric or generatoric operation.
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.14 peak utilization 020Eh RO - - 0 65535 1 % -
ru.14 permits the detection of short-time peak loads within an operating cycle. The highest value of ru.13 is
stored in ru.14. The peak value memory can be cleared by pressing the keys UP, DOWN or ENTER and by bus
through writing any chosen value to the address of ru.14. The switch off of the inverter also clears the memory.
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.15 apparent current 020Fh RO - - 0 6553.5 0.1 A -
Display of the actual apparent current.
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.16 apparent current 0210h RO - - 0 6553.5 0.1 A -
ru.16 permits the detection of short-time peak currents within an operating cycle. The highest value of ru.15 is
stored in ru.16. The peak value memory can be cleared by pressing the keys UP, DOWN or ENTER and by bus
through writing any chosen value to the address of ru.16. The switch off of the inverter also clears the memory.
