Operating and appliance data
© KEB, 2012-10 COMBIVERT F5-A, -E, -H Page 7.1 - 23
7
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
SY.43 Control word long 002Bh RW - + -2147483648 2147483647 1 - 0
The control word is used for state control of the inverter via bus. The control word long (Sy.43) consists of the
two 16 bit parameters control word high (Sy.41) and control word low (Sy.50). The status word is bit-coded.
The description of the individual bits is found in chapter 10.1.
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
SY.44 Status word long 002Ch RO - - -2147483648 2147483647 1 - 0
With the status word the current condition of the inverter can be readout via bus. The status word long (Sy.44)
consists of the two 16 bit parameters status word high (Sy.42) and status word low (Sy.51). The status word
is bit-coded. The description of the individual bits is found in chapter 10.1.
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
SY.50 Control word low 0032h RW - + 0 65535 1 - 0
The control word is used for state control of the inverter via bus. The control word long (Sy.43) consists of the
two 16 bit parameters control word high (Sy.41) and Control word low (Sy.50). The status word is bit-coded.
The description of the individual bits is found in chapter 10.1.
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
Sy. 51 Control word low 0033h RO - - 0 65535 1 - 0
With the status word the current condition of the inverter can be readout via bus. The status word long (Sy.44)
consists of the two 16 bit parameters status word high (Sy.42) and status word low (Sy.51). The status word
is bit-coded. The description of the individual bits is found in chapter 10.1.
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
SY.52 Set speed value 0034h RW - - -32000 32000 1 rpm 0
Setting of the set speed value in the range of ±16000 rpm. The rotation source is determined like the other
absolute reference sources via oP.01. The reference source oP.00 must be adjusted for setpoint setting via
SY.52 to „5“.
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
SY.53 Actual speed value 0035h RO - - -32000 32000 1 rpm 0
The actual speed can be read out in rpm with this parameter. The direction of rotation is signalled by the sign.
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
Sy.56 Start display address 0035h RO - + 0 7FFFFh 1 hex 0203
Sy.56 adjusts the parameter address which shall be represented on switching on the operator. Operator pa-
rameters can also be adjusted as starting display. Only valid addresses are accepted. If there is adjusted an
invalid address (neither in the inverter nor assigned in the operator) the operator searches for the next existing
address of the parameter group.
If this parameters is available in the CP-Mode, the setting becomes effective there. Otherwise CP.00 is indi-
cated as start parameter.
