Operating and appliance data
© KEB, 2012-10 COMBIVERT F5-A, -E, -H Page 7.1 - 25
7
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
SY.78 Status word S4 004Eh RO - + 0 7FFFFh 1 hex 0
A compatible control or status word has been introduced in order to permit an easier replace of old S4 appli-
cations with F5.
Mapping of the control word of the S4 30F software
Bit Function
0 OUTA
1 OUTB
2 OUTC
3 OUTD
4-7 free
8 ST
9 RST
10 F
11 R
12 I1
13 I2
14 I3
15 free
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
SY.79 Status word 1 PROFI-
drive
004F RO - - 0 7FFFFh 1 hex 0
Status word 1: All unlisted bits are set to 0:
Bit -No. Description
3 Malfunction
8 No set-actual deviation
11 Malfunction undervoltage
