Keithley 2015 Service Manual

6-4 Replaceable Parts
Circuit designation Description
Keithley
part no.
C209 CAP, 22UF, 20%, 25V, TANTALUM C-440-22
C240,244 CAP, 1000pF, 20%, 50V, CERAMIC C-418-1000P
C241 CAP, .01UF, 10%, 50V, CERAMIC C-491-.01
C242,243 CAP, .01UF, 10%, 50V, CERAMIC C-491-.01
C251,253 CAP, 47PF, 10%, 100V, CERAMIC C-451-47P
C252 CAP, 22PF, 10%, 100V, CERAMIC C-451-22P
C254,263 CAP, 47P, 5%, 100V, CERAMIC C-465-47P
C255-258 CAP, 270PF, 5%, 100V, CERAMIC C-465-270P
C264,265 CAP, 22P 5%, 100V CERAMIC C-465-22P
C266 CAP, 10000PF, 20%, 63V, POLY-FILM C-471-10000P
CR102,103 DIODE, BRIDGE, VM18 RF-52
CR104 DIODE, SILICON, W04M RF-46
CR105,108,114 DIODE, SWITCHING, MMBD914 RF-83
CR106 DIODE, BRIDGE PE05 RF-48
CR110,118 DIODE, DUAL HSM-2822T31 RF-95
CR111,112,115-117 DIODE, DUAL SWITCHING, BAV99L RF-82
E101,102 SURGE ARRESTOR, CG3-1.5L SA-4
J1006 CONN, MICRODIN W/GND FINGERS CS-792
J1007 CONN, RT ANGLE, MALE, 9 PIN CS-761-9
J1008 CONN, RIGHT ANGLE, 24 PIN CS-501
J1014 CONN, HEADER STRAIGHT SOLDER PIN CS-368-16
J1015 CONNECTOR, HEADER CS-784-4
J1016 CONN, MALE, 5-PIN (MOLEX 42491) CS-784-5
J1017 CONNECTOR, HEADER STRAIGHT
SOLDER PIN
CS-368-14
J1022 LATCHING HEADER, FRICTON, SGL ROW CS-724-3
J1024 LATCHING HEADER, 5-PIN CS-724-5
J1026 CONN, BERG 4-PIN CS-724-4
K101,102 RELAY, MINATURE (DPDT) TQ2E-L2-5V RL-155
K103 RELAY, MINI SIGNAL REL RL-163
L101-104 FERRITE CHIP 600 OHM BLM32A07 CH-62
L105,106 FERRITE CHIP 600 OHM BLM32A07 CH-62
L107,108 CHOKE CH-61
L109 CHOKE CH-63-22
LS101 BEEPER, 5V, 30MA, BRT1209P-06-C EM-5
Q101,102 TRANS, N-CHAN MOSFET, 2SK1412 TG-276
Q103,110,112,115,118,128,130 TRANS, NPN, MMBT3904 TG-238
Q104-109,113,114,120,123-126,135 TRANS, N CHANNEL JFET, SNJ132199 TG-294
Table 6-1
DMM (mother) board parts list (continued)

Keithley 2015 Specifications

General

Model	Keithley 2015
Category	Multimeter
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 300 kHz
Resistance Range	100 MΩ
DC Current Range	3 A
DC Current Accuracy	0.05%
AC Current Range	3 A
Display	5.5 digit
Connectivity	GPIB
Power Supply	100 V to 240 V AC, 50 Hz to 60 Hz
