Keithley 2015 Service Manual

Replaceable Parts 6-3
Table 6-1
DMM (mother) board parts list
Circuit designation Description
Keithley
part no.
AT101 IC, DUAL HIGH CMR/SPEED OPTO,
HCPL-2631
IC-588
C102 CAP, .01UF, 10%, 1000V, CERAMIC C-64-.01
C103,128,149,161,167,169,172,178,223,
250
CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C104 CAP, 100UF, 20%, 63V, ALUM ELEC C-403-100
C105 CAP, .22UF, 20%, 400V, FILM C-513-.22
C106 CAP, 15P, 1%, 100V, CERAMIC C-512-15P
C107 CAP, .1UF, 20%, 50V, CERAMIC C-418-.1
C108 CAP, .1UF, 20%, 100V, CERAMIC C-436-.1
C109 CAP, 2.2UF, 20%, 63V, POLYCARB C-480-2.2
C110,141,150,158,176,219,220,222,224,
226
CAP, 47P, 5%, 100V, CERAMIC C-465-47P
C111,116,118,122,153,155,202,210,
225,227
CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C112,248 CAP, .01, 5%, 50V, NPO C-514-.01
C113,114,119,126,247 CAP, 1000P, 10%, 100V, CERAMIC C-451-1000P
C115 CAP, .33UF, 20%, 63V, POLYCARBONATE C-482-.33
C117,147,151,191,234,237 CAP, .1UF, 20%, 50V, CERAMIC C-418-.1
C120 CAP, 270PF, 5%, 100V, CERAMIC C-465-270P
C121,132,134,140 CAP, 220PF, 10%, 100V, CERAMIC C-451-220P
C123,245 CAP, 1000P, 10%, 100V, CERAMIC C-451-1000P
C124,133,154,159,181,192,196,212,213,
230,
CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C125,138,139,142,152,162,173,190,204-
206
CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C131,148 CAP, 2200UF, 20%, 35V, ALUM ELEC C-468-2200
C135,183,187,197,198,203,249 CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C136,170,182,193,194,199, 200,201,233,
232
CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C137 CAP, 33PF, 5%, 100V, CERAMIC C-465-33P
C145 CAP, 1000pF, 20%, 50V, CERAMIC C-418-1000P
C146 CAP, 3300UF, 20%, 16V ALUM ELEC C-473-3300
C156 CAP, 6800UF, -20+100%, 16V, ALUMINUM C-313-6800
C157,179 CAP, 100PF, 5%, 100V, CERAMIC C-465-100P
C160,163,174,180,186,207,208,214-218 CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C168,185,221 CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C171,177 CAP, 2200P, 10%, 100V, CERAMIC C-430-2200P
C175 CAP, 10UF, 20%, 25V, TANTALUM C-440-10

Keithley 2015 Specifications

General

Model	Keithley 2015
Category	Multimeter
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 300 kHz
Resistance Range	100 MΩ
DC Current Range	3 A
DC Current Accuracy	0.05%
AC Current Range	3 A
Display	5.5 digit
Connectivity	GPIB
Power Supply	100 V to 240 V AC, 50 Hz to 60 Hz
