Keithley 2015 Service Manual

Replaceable Parts 6-9
* Order current firmware revision (for example, A02).
Table 6-2
Display board parts list
Circuit designation Description
Keithley
part no.
C401,402,411 CAP, .1UF, 20%, 50V, CERAMIC C-418-.1
C403,404,405,407,409,410,412 CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C406,408 CAP, 33PF, 10%, 100V, CERAMIC C-451-33P
C413 CAP, 22UF, 20%, 6.3, TANTALUM C-417-22
CR401,402 DIODE, MBR0520LT1 RF-103
DS401 DISPLAY DD-52
P1014 CABLE ASSEMBLY CA-123-16A
R401,402,403,404,406,409,411,414-416 RES, 15k, 1%, 100MW, THICK FILM R-418-15K
R405,408,410,412 RES, 12.1, 1%, 125MW, METAL FILM R-391-12.1
R413 RES, 13K, 1%, 100MW, THICK FILM R-418-13K
R417,418 RES, 15k, 1%, 100MW, THICK FILM R-418-15K
R419 RES, 10M, 5%, 125MW, METAL FILM R-375-10M
R420,421 RES, 10K, 1%, 100MW, THICK FILM R-418-10K
U401 PROGRAMMED ROM 2000-800*
U402,403 IC, LATCHED DRIVERS, UCN-5812EPF-1 IC-732
Y401 CRYSTAL, 4MHZ CR-36-4M

Keithley 2015 Specifications

General

Model	Keithley 2015
Category	Multimeter
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 300 kHz
Resistance Range	100 MΩ
DC Current Range	3 A
DC Current Accuracy	0.05%
AC Current Range	3 A
Display	5.5 digit
Connectivity	GPIB
Power Supply	100 V to 240 V AC, 50 Hz to 60 Hz
