Keithley 2015 Service Manual

Calibration Reference B-9
DC calibration commands
The :DC commands perform calibration of the DCV, DCI, and ohms functions. Table B-2
summarizes these calibration commands along with parameter limits.
Table B-2
DC calibration commands
:STEP1
(:CALibration:PROTected:DC:STEP1)
Purpose To perform front terminal short-circuit calibration.
Format :cal:prot:dc:step1
Parameter None
Description :STEP1 performs the short-circuit calibration step in the comprehensive cal-
ibration procedure. Connect a low-thermal short (Model 8610) to the front
panel input jacks before sending this command.
Example :CAL:PROT:DC:STEP1 Perform short-circuit calibration.
Command Description Parameter limits
:CALibration
:PROTected
:DC
:STEP1 Front terminal short circuit.
:STEP2 Open circuit.
:STEP3 <NRf> 10V DC calibration step. 9 to 11
:STEP4 <NRf> -10V DC calibration step. -9 to -11
:STEP5 <NRf> 100V DC calibration step. 90 to 110
:STEP6 <NRf> 1kΩ 4-wire calibration step. 900 to 1.1E3
:STEP7 <NRf> 10kΩ 4-wire calibration step. 9E3 to 11E3
:STEP8 <NRf> 100kΩ 4-wire calibration step. 90E3 to 110E3
:STEP9 <NRf> 1MΩ 4-wire calibration step. 900E3 to 1.1E6
:STEP10 <NRf> 10mA DC calibration step. 9E-3 to 11E-3
:STEP11 <NRf> 100mA DC calibration step. 90E-3 to 110E-3
:STEP12 <NRf> 1A DC calibration step. 0.9 to 1.1

Keithley 2015 Specifications

General

Model	Keithley 2015
Category	Multimeter
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 300 kHz
Resistance Range	100 MΩ
DC Current Range	3 A
DC Current Accuracy	0.05%
AC Current Range	3 A
Display	5.5 digit
Connectivity	GPIB
Power Supply	100 V to 240 V AC, 50 Hz to 60 Hz
