Keithley 2015 Service Manual

6-10 Replaceable Parts
Table 6-3
Distortion (DSP) board parts list
Circuit designation Description
Keithley
part no.
C301,310,352,505,508,532,538,571 CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C302,313,323,354,560,561,378-387, CAP, .01UF, 10%, 50V, CERAMIC C-491-.01
C303,325,355,399,511,550,573,344 CAP, 10U, 20%, 16V, TANTALUM C-546-10
C304,305,396,397 CAP, 2200P, 1%, 50V, CERAMIC C-532-2200P
C306,308,315-322,327,340-343,345,349,
356
CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C309,517,525 CAP, 1000P, 10%, 100V, CERAMIC C-451-1000P
C312,314,329-338,506,507,509,533-537,
570
CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C324 CAP, 7.5P, 10%, 100V, CERAMIC C-452-7.5P
C326 CAP, 100U, 20%, 16V, ALUM ELEC C-547-100
C339,366 CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C346,347 CAP, 47UF, 20%, 100V, ALUM ELEC C-521-47
C350 CAPACITOR C-473-4700
C353,357,388,389 CAP, .01UF, 10%, 50V, CERAMIC C-491-.01
C358-365,523,524 CAP, 100PF, 5%, 100V, CERAMIC C-465-100P
C367 CAP, 22UF, 20%, 25V, TANTALUM C-440-22
C368-376,551-558,563,564,566,567,569 CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C377,390,391 CAP, 10U, 20%, 16V, TANTALUM C-546-10
C392,393,500,504,510,512,519-522,532 CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C395,515 CAP, 220PF, 10%, 100V, CERAMIC C-451-220P
C503 CAP, 33PF, 5%, 100V, CERAMIC C-465-33P
C513 CAPACITOR C-576-.022
C514 CAP, 2200P, 1%, 50V, CERAMIC C-532-2200P
C516 CAP, .1UF, 20%, 63V, POLYCARBONATE C-482-.1
C518 CAP, .01, 5%, 50V, NPO C-514-.01
C527,528,572 CAP, 1000P, 10%, 100V, CERAMIC C-451-1000P
C562,565 CAP, 1000UF, 20%, 50V, ALUM ELEC C-469-1000
C568 CAP, 2200UF, -20 +100%, 25V, ALUM ELEC C-314-2200
C574,575 CAP, 10UF, 20%, 25V, TANTALUM C-440-10
CR301 SCHOTTKY DIODE RF-121
CR302,303 DIODE, SWITCHING, MMBD914 RF-83
CR305-311 DIODE, SWITCHING, MMSD914T19 RF-112
CR330,331 DIODE, SILICON, W04M RF-46

Keithley 2015 Specifications

General

Model	Keithley 2015
Category	Multimeter
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 300 kHz
Resistance Range	100 MΩ
DC Current Range	3 A
DC Current Accuracy	0.05%
AC Current Range	3 A
Display	5.5 digit
Connectivity	GPIB
Power Supply	100 V to 240 V AC, 50 Hz to 60 Hz
