Replaceable Parts 6-11
Circuit designation Description
Keithley
part no.
HS331 HEAT SINK HS-55
J1018,1019,1021 CONNECTOR, HEADER CS-784-6
J1020 CONN, MALE 3 PIN CS-784-3
J1028,1029 CONN, BNC RIGHT ANGLE PLASTIC CS-506
J1030 CONN, DUAL 10-PIN-BERG CS-389-8
J1031 CONN, MALE, 5-PIN (MOLEX 42491) CS-784-5
K301 RELAY, MINI SIGNAL REL RL-163
L301-303,305,311-313,315,318,323 FERRITE CHIP 600 OHM BLM32A07 CH-62
L306-309 CHOKE CH-90-5
L310,319-321 FERRITE BEAD CH-91
L314,316,317,322 CHOKE CH-61
P1017 CABLE ASSEMBLY CA-123-1A
Q301 TRANS, N-MOSFET, VN0605T TG-243
Q302 TRANS, PNP, MMBT3906L TG-244
R301,326 RES, 2K, 1%, 100MW, THICK FILM R-418-2K
R302,303,306,307 RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R304,305 RES, 49.9, 1%, 100MW, THICK FILM R-418-49.9
R308,310,316 RES, 10, 10%, 100MW, THICK FILM R-418-10
R309,311,313,320,557 RES, 100, 1%, 100MW, THICK FILM R-418-100
R312 RES, 174, 1%, 100MW, THICK FILM R-418-174
R314,317,-319,339,342,534,535 RES, 100, 1%, 100MW, THICK FILM R-418-100
R315,352,354,355,356,358,362 RES, 475, 1%, 100MW, THICK FILM R-418-475
R321,348-351,357,559 RES, 475, 1%, 100MW, THICK FILM R-418-475
R322,500 RES, 49.9, 1%, 100MW, THICK FILM R-418-49.9
R323 RES, 30.1K, 1%, 100MW, THICK FILM R-418-30.1K
R327,509,510,511 RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R328,330,331,523 RES, 2K, 1%, 100MW, THICK FILM R-418-2K
R329,332-334,364-390,501,512-514,546 RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R338,520,530 RES, 10, 10%, 100MW, THICK FILM R-418-10
R340,343,515,537-540 RES, 200, 1%, 100MW, THICK FILM R-418-200
R341,344,507,508,527,532,533,558 RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R345-347,360,361,363,550-552 RES, 2.21K, 1%, 100MW, THICK FILM R-418-2.21K
R359,518,521,524 RES, 7.5K, 1%, 100MW, THICK FILM R-418-7.5K
Table 6-3
Distortion (DSP) board parts list (continued)
