6-12 Replaceable Parts
Circuit designation Description
Keithley
part no.
R392-394,542,547,553-555 RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R396-399 RES, 274, 1%, 100MW, THICK FILM R-418-274
R502 RES, 4.75K, 1%, 100MW, THICK FILM R-418-4.75K
R503-506 RES, 22.1K, 1%, 100MW, THICK FILM R-418-22.1K
R516 RES, 200, 1%, 100MW, THICK FILM R-418-200
R517 RES, 20K, 1%, 100MW, THICK FILM R-418-20K
R519,526 RES, 45.3K, 1%, 100MW, THICK FILM R-418-45.3K
R522 RES, 49.9K, 1%, 100MW, THICK FILM R-418-49.9K
R525 RES, 15k, 1%, 100MW, THICK FILM R-418-15K
R531 RES, 14K, 1%, 100MW, THICK FILM R-418-14K
R536,548 RES,4.02K,1%,100MW, THICK FILM R-418-4.02K
R541 RES, 100K, 1%, 100MW, THICK FILM R-418-100K
R543 RES, 499K, 1%, 100MW, THICK FILM R-418-499K
R544 RES, 7.5K, 1%, 100MW, THICK FILM R-418-7.5K
R545 RES, 1.74K, 1%, 100MW, THICK FILM R-418-1.74K
R549 RES, 3.65K, 1%, 100MW, THICK FILM R-418-3.65K
R560 RES, .0499, 1%, 100MW, THICK FILM R-418-.0499
R561 RES, 26.7K, 1%, 100MW, THICK FILM R-418-26.7K
R562 RES, 66.5K, 1%, 100MW, THICK FILM R-418-66.5K
R563 RES, 150K, 1%, 100MW, THICK FILM R-418-150K
R564 RES, 110K, 1%, 100MW, THICK FILM R-418-110K
RV301-304 VARISTOR VR-17
SO315,326,346 SOCKET SO-72
SO330 SOCKET PLCC-032-T-A SO-143-32
TP301,304,308-310 CONNECTOR CS-985
U301-325 CMOS, COMPLETE DDS SYNTHESIZER IC-1141
U302 12-BIT VOLTAGE OUTPUT DAC IC-1130
U303 IC, DIFF. AMP, AMP03GP IC-988
U305-308,339-343 IC, J-FET, OP-AMP, TLE2081CD IC-967
U309,310,335 DUAL BIPOLAR/JFET OPAMP IC-1203
U311 LARGE SCALE IC SMT LSI-216
U312,313,322,323 IC, HEX SCHMITT INV TRIGG 74HC14 IC-1103
U314,327,344 IC, FPGA, XC5202 LSI-193
Table 6-3
Distortion (DSP) board parts list (continued)
