Keithley 2015 Service Manual

6-6 Replaceable Parts
Circuit designation Description
Keithley
part no.
R160,167,172 RES, 1M, 1%, 100MW, THICK FILM R-418-1M
R161,178,184,187,213,248,257,308,
331,332
RES, 100, 1%, 100MW, THICK FILM R-418-100
R168 RES, 270, 5%, 250mW, METAL FILM R-376-270
R169,214,218 RES, 4.99K, 1%, 100MW, THICK FILM R-418-4.99K
R188 RES, 49.9, 1%, 125mW, METAL FILM R-391-49.9
R189 RES, 3.01K, 1%, 125MW, METAL FILM R-391-3.01K
R192 RES, 6.98K, 1%, 125MW, METAL FILM R-391-6.98K
R194 RESISTOR, METAL FILM R-443-7.06K
R195 RESISTOR, METAL FILM R-443-70.6K
R201,204,206,208-211,223,229,231,233 RES, 4.75K, 1%, 100MW, THICK FILM R-418-4.75K
R202,224,249,263,319 RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R205 RES, 10, .5%, 1/8W, METAL FILM R-246-10
R212,217,220,221,264,329,330 RES, 2.21K, 1%, 100MW, THICK FILM R-418-2.21K
R215 RES, 4.42K, 1%, 125MW, METAL FILM R-391-4.42K
R216 RES, 2.21K, 1%, 125mW, METAL FILM R-391-2.21K
R225 RES, 470, 5%, 125MW, METAL FILM R-375-470
R226,228,235,237,250,252,255 RES, 475, 1%, 100MW, THICK FILM R-418-475
R234 RES, 5.11K, 1%, 100MW, THICK FILM R-418-5.11K
R238,244,254,293 RES, 4.75K, 1%, 100MW, THICK FILM R-418-4.75K
R241 RES, 34K, 1%, 100MW, THICK FILM R-418-34K
R243,259 RES, 10, 10%, 100MW, THICK FILM R-418-10
R245 RES, 475, 1%, 100MW, THICK FILM R-418-475
R246 RES, 82.5, 1%, 100MW, THICK FILM R-418-82.5
R261 RES, 200, 1%, 100MW, THICK FILM R-418-200
R267,270 RES, .0499, 1%, 100MW, THICK FILM R-418-.0499
R271 RES NET TF-245
R273,274 RES, 475, 1%, 125mW, METAL FILM R-391-475
R277 RES, 66.5K, 1%, 100MW, THICK FILM R-418-66.5K
R280,294 RES, 49.9, 1%, 100MW THICK FILM R-418-49.9
R283 RES, 470, 5%, 125MW, METAL FILM R-375-470
R287 RES, 1.28M, .1%, 1/8W METAL FILM R-176-1.28M
R288,289,290,333 RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R291,292 RES, 47.5K, 1%, 100MW THICK FILM R-418-47.5K
R297,278,281 RES, 357, 1%, 100MW, THICK FILM R-418-357
R300 RES, 2.15K, 1%, 125MW, THIN FILM R-423-2.15K
R302,303 RES, 499, 1%, 100MW, THICK FILM R-418-499
R304 RES, 20K, 1%, 100MW, THICK FILM R-418-20K
Table 6-1
DMM (mother) board parts list (continued)

Keithley 2015 Specifications

General

Model	Keithley 2015
Category	Multimeter
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 300 kHz
Resistance Range	100 MΩ
DC Current Range	3 A
DC Current Accuracy	0.05%
AC Current Range	3 A
Display	5.5 digit
Connectivity	GPIB
Power Supply	100 V to 240 V AC, 50 Hz to 60 Hz
