8-4 Triggering Model 2750 Multimeter/Switch System User’s Manual
The delay function is accessed by pressing SHIFT and then DELAY. The present delay
setting (AUTO or MANual) is displayed. Press the
Δ or ∇ key to display the desired set-
ting and press ENTER.
If MANual is chosen, also enter the duration of the delay in the hour/minute/second for-
mat using the , ,
Δ , and ∇ keys. The maximum is 99H:99M:99SS. Note that press-
ing the AUTO key sets the delay to 0.001 sec. Press ENTER to accept the delay or EXIT
for no change.
Table 8-1
Auto delay settings
Function Range and delay
DCV 100mV
1ms
1V
1ms
10V
1ms
100V
5ms
1000V
5ms
ACV 100mV
400ms
1V
400ms
10V
400ms
100V
400ms
750V
400ms
FREQ and
PERIOD
100mV
1ms
1V
1ms
10V
1ms
100V
1ms
750V
1ms
DCI 20mA
2ms
100mA
2ms
1A
2ms
3A
2ms
ACI 1A
400ms
3A
400ms
Ω2, Ω4
1
1Ω
2
3ms
10Ω
3ms
100Ω
3ms
1kΩ
3ms
10kΩ
13ms
100kΩ
25ms
1MΩ
100ms
10MΩ
150ms
100MΩ
250ms
Dry Circuit
Ohms
3
1Ω
3ms
10Ω
3ms
100Ω
13ms
1kΩ
13ms
Continuity 1kΩ
3ms
TEMP The auto delay for thermocouples is 1ms. For thermistors and 4-wire RTDs, the auto delay
period is the same as the delay for the resistance range that is used for the measurement.
1. Delay times also apply for offset-compensated ohms (OCOMP).
2. 1Ω range not available for the Ω2 function.
3. State (on or off) of offset-compensated ohms (OCOMP) does not affect delay times.
2750-900-01.book Page 4 Wednesday, August 3, 2011 7:56 AM
