Keithley 2750 User Manual

Model 2750 Multimeter/Switch System User’s Manual Range, Digits, Rate, Bandwidth, and Filter 4-19
Remote programming — filter
Filter commands
The filter commands are listed in Table 4-6. Additional information on these commands
follow the table.
NOTE Query commands are not included in Table 4-6. All commands for the SENSe
subsystem are provided in Table 15-5.
Table 4-6
Filter commands
Commands
1, 4
Description
5
Default
DCV filter commands
[SENSe[1]] Optional root command.
:VOLTage[:DC]:AVERage:TCONtrol <name> Select filter type; <name> = MOVing or
REPeat.
(Note 2)
:VOLTage[:DC]:AVERage:WINDow <NRf> Set filter window in %; <NRf> = 0 to 10. 0.1
:VOLTage[:DC]:AVERage:COUNt <n> [,
clist]
Specify filter count; <n> = 1 to 100. 10
:VOLTage[:DC]:AVERage:STATe <b> [, clist] Enable or disable the filter. (Note 3)
ACV filter commands
[SENSe[1]] Optional root command.
:VOLTage:AC:AVERage:TCONtrol <name> Select filter type; <name> = MOVing or
REPeat.
(Note 2)
:VOLTage:AC:AVERage:WINDow <NRf> Set filter window in %; <NRf> = 0 to 10. 0.1
:VOLTage:AC:AVERage:COUNt <n> [, clist] Specify filter count; <n> = 1 to 100. 10
:VOLTage:AC:AVERage:STATe <b> [, clist] Enable or disable the filter. (Note 3)
2750-900-01.book Page 19 Wednesday, August 3, 2011 7:56 AM

Keithley 2750 Specifications

General

Interface	GPIB, RS-232, Ethernet
Switching Speed	Up to 500 channels/second
Maximum Voltage	300V
Operating Temperature	0°C to 50°C
Measurement Functions	DCV, ACV, DCI, ACI, 2-wire Resistance, 4-wire Resistance, Frequency, Temperature
Resolution	6.5 digits
Current	1A
Maximum Current	1A
