9-18 Limits and Digital I/O Model 2750 Multimeter/Switch System User’s Manual
Remote Operation — For remote operation, make sure both Limit 1 and Limit 2 are
enabled. The following table evaluates the three possible pass/fail combinations for this
example.
Keep in mind that a fail condition must be reset before testing the next resistor. Fail can be
reset manually or automatically (see Table 9-2, CLEar command).
Digital outputs
With the digital outputs of the Model 2750 enabled, the digital outputs will respond as fol-
lows for each resistor reading:
Limit 1 result Limit 2 result Resistor tolerance Bin assignment
Pass Pass >1% 1
Fail Pass >5% 2
Fail Fail >5% 3
LO limit 2 LO limit 1 HI limit 1 HI limit 2
Resistor
tolerance Bin
Affected
outputs*
Pass Pass Pass Pass 1% 1 None
Pass Fail Pass Pass 5% 2 #1 and #5
Pass Pass Fail Pass 5% 2 #2 and #5
Fail Fail Pass Pass >5% 3 #1, #3 and #5
Pass Pass Fail Fail >5% 3 #2, #4 and #5
*Affected outputs are pulled (or pulsed) high or low when a limit test fails.
2750-900-01.book Page 18 Wednesday, August 3, 2011 7:56 AM

Keithley 2750 Specifications

General

Interface	GPIB, RS-232, Ethernet
Switching Speed	Up to 500 channels/second
Maximum Voltage	300V
Operating Temperature	0°C to 50°C
Measurement Functions	DCV, ACV, DCI, ACI, 2-wire Resistance, 4-wire Resistance, Frequency, Temperature
Resolution	6.5 digits
Current	1A
Maximum Current	1A
