B-10 Model 7700 Connection Guide Model 2750 Multimeter/Switch System User’s Manual
Figure B-9
Voltage connections (DC or AC)
Connection log
Make a copy of Table B-1 and affix it to the cover of the Model 7700. Use this to record
connection information and channel descriptions as needed.
Channel 1
HI
LO
Channel 20
HI
LO
(Channels 2–19)
+
+
DC Voltage AC Voltage
