15-8 SCPI Reference Tables Model 2750 Multimeter/Switch System User’s Manual
ROUTe
:SCAN Path to configure scan: Sec 7 ✓
[:INTernal] <clist> Specify list of channels to be scanned. ✓
[:INTernal]? Query scan list. ✓
:TSOurce <list> Select trigger source to start the scan (IMM, or
HLIM1, HLIM2, LLIM1, and LLIM2).
IMM
:TSOurce? Query trigger source for scan.
:NVOLatile <b> Enable or disable nonvolatile memory for
scanning (autoscan).
(Note 2)
:NVOLatile? Query nonvolatile memory setting.
:LSELect <name> Enable (INTernal) or disable (NONE) scan. NONE
:LSELect? Query state of scan.
Notes:
1. Default value depends on which switching module is installed.
2. Not affected by *RST and SYSTem:PRESet. Front panel factory default is OFF.
3. Not affected by *RST and SYSTem:PRESet. Interval set to 15 minutes at the factory.
4. The ROUT:MULT:CLOS command cannot be used to measure thermocouple temperature using the internal or external refer-
ence junction. The simulated reference junction will instead be used. See “Temperature measurements,” page 3-25, for details.
Table 15-5
SENSe command summary
Command Description
Default
parameter Ref SCPI
[SENSe[1]]
:FUNCtion <name>
[, <clist>]
Select function: ‘VOLTage[:DC]’,
‘VOLTage :AC’, ‘CURRent[:DC]’,
‘CURRent:AC’, ‘RESistance’,
‘FRESistance’, ‘TEMPerature’,
‘FREQuency’, ‘PERiod’, ‘CONTinuity’.
VOLT:DC Sec 3 ✓
:FUNCtion? [<clist>] Query function. ✓
:DATA[:LATest]? Return the last reading. Sec 3 ✓
:DATA:FRESh? Return the last “fresh” reading. Sec 3
:CAVerage <b> [, <clist>] Channel average calculation: Sec 5
:DELay <NRf> [, <clist>] Set delay between the two measurements
in seconds (0 to 99999.999).
1
0.5
:DELay? [<clist>] Query delay.
[:STATe] <b> [, <clist>] Enable or disable channel average. OFF
[:STATe]? [, <clist>] Query state of channel average.
:RATio <b> [, <clist>] Channel ratio calculation: OFF Sec 5
Table 15-4 (continued)
ROUTe command summary
Command Description
Default
parameter Ref SCPI
2750-900-01.book Page 8 Wednesday, August 3, 2011 7:56 AM

Keithley 2750 Specifications

General

Interface	GPIB, RS-232, Ethernet
Switching Speed	Up to 500 channels/second
Maximum Voltage	300V
Operating Temperature	0°C to 50°C
Measurement Functions	DCV, ACV, DCI, ACI, 2-wire Resistance, 4-wire Resistance, Frequency, Temperature
Resolution	6.5 digits
Current	1A
Maximum Current	1A
