Kia Carnival - Page 756

Maintenance
708
Fuses
E-SHIFTER 10A
[With SBW (Shift By Wire)] Electronic ATM (Automatic
Transmission) Shift Lever Switch
MODULE5 10A Overhead Console Indicator
A/C 7.5A
Front A/C Control Module, Front A/C Control Panel, Engine
Room Junction Block (Front Blower Relay, PTC Heater2
Relay)
AIR BAG2 10A SRS Control Module (B+)
CLUSTER 7.5A Instrument Cluster (IG1)
MODULE4 10A
Data Link Connector, Audio, A/V & Navigation Head Unit,
Keyboard, Head Lamp LH/RH, Wireless Charger, Emer
-
gency Call (E-Call) Module, Front/Rear A/C Control Module,
Rear Power Window Switch LH/RH, Front A/C Control
Panel, Rear Safety Power Window Switch LH/RH, Driver
IMS (Integrated memory system) Control Module, Front
Seat Warmer Control Module, Electro Chromic Mirror,
Front Air Ventilation Seat Control Module, 2nd Seat
Warmer Control Module, 2nd Seat LH/RH Relax Module,
Overhead Console, 2nd Seat LH/RH Air Ventilation Control
Module
MODULE7 7.5A IBU (Integrated Body Control Unit) (IG2)
BRAKE
SWITCH
7.5A IBU (Integrated Body Control Unit), Stop Lamp Switch
EPS 7.5A EPS (Electric Power Steering) Unit
MULTI MEDIA2 10A
[Without BOSE AMP (Amplifier)] A/V & Navigation Head
Unit
Fuse Name Symbol Fuse rating Circuit Protected
E-SHIFTER
MODULE
5
A/C
2
CLUSTER
MODULE
4
MODULE
7
BRAKE
SWITCH
1
MULTI
MEDIA
2
