Kia Carnival - Page 755

69
8
8
Maintenance Fuses
MEMORY 10A
Front/Rear A/C Control Module, Front A/C Control Panel,
Instrument Cluster, Rear Seat Multimedia Monitor LH/RH,
Driver/Passenger Power Outside Mirror, Driver IMS (Inte
-
grated memory system) Control Module, Power Tail Gate
Module, Rear Occupant Alert (ROA) Sensor #1/#2, Sur
-
round View Monitor
START 10A [Without Smart Key] Ignition Switch
MODULE6 7.5A [Smartstream D2.2] Diesel Filter Heater
USB CHARGER 15A
Luggage USB Charger LH, Luggage USB Charger Unit,
Driver Seat USB Jack, Passenger Seat USB Jack
MODULE3 7.5A
IBU (Integrated Body Control Unit), ADAS Unit, Lane Depar
-
ture Warning (LDW) Camera, Crash Pad Switch, Electric
Parking Brake Switch, Front Upper Console Switch, ATM
(Automatic Transmission) Shift Lever Indicator, Rear Radar
LH/RH, Dosing Control Module
AIR BAG1 15A
SRS (Supplemental Restraint System) Control Module
(IG1), OCCUPANT DETECTION SENSOR
WASHER 15A Multifunction Switch
MODULE1 10A
IBU (Integrated Body Control Unit), Audio, A/V & Navigation
Head Unit, Keyboard, ADAS Unit, Emergency Call (E-Call)
Module, FRONT TRAY USB CHARGER, AMP (Amplifier)
(BOSE), Rear Seat Multimedia Monitor LH/RH
MODULE9 10A
Data Link Connector, Hazard Switch, 2nd Seat LH/RH Relax
Module, ATM (Automatic Transmission) Shift Lever, Crash
Pad Switch, Crash Pad Switch (Lower), Driver Door Module,
Driver/Passenger Door Outside Handle, Driver/Passenger
Door Outside Handle Antenna, Rain Sensor
IBU1 7.5A IBU (Integrated Body Control Unit) (IG1)
MODULE2 7.5A Stop Lamp Switch
REAR A/C 10A
Rear A/C Control Module, Engine Room Junction Block
(Rear Blower Relay)
AIR BAG IND. 7.5A Instrument Cluster, AIR BAG(TELLTALE LAMP)
MODULE8 7.5A
AC Inverter Module, 2nd Seat LH/RH Air Ventilation Control
Module, AC Inverter (Rear), Front Air Ventilation Seat Con
-
trol Module, Engine Room Junction Block (Windscreen
Heated Glass 1/2 Relay), 2nd Seat Warmer Control Module,
2nd Seat LH/RH Relax Module
IBU2 15A IBU (Integrated Body Control Unit) (B+)
Fuse Name Symbol Fuse rating Circuit Protected
MEMORY
MODULE
6
USB
CHARGER
MODULE
3
1
MODULE
1
MODULE
9
IBU
1
MODULE
2
REAR A/C
IND
MODULE
8
IBU
2
