Kia Carnival - Page 760

Maintenance
748
Fuses
PCB Block
POWER OUTLET4 20A Rear Power Outlet
INVERTER 40A AC Inverter Module
E-SHIFTER2 10A
[With SBW (Shift By Wire)] SCU (System Control Unit),
Electronic ATM (Automatic Transmission) Shift Lever
Switch
FUEL PUMP 20A Fuel Pump Relay
Fuse Name Symbol Fuse rating Circuit Protected
POWER
OUTLET
4
INVERTER
E-SHIFTER
2
FUEL
PUMP
Fuse Name Symbol Fuse rating Circuit Protected
IG2 40A IG2 Relay, Engine Room Junction Block (Start1 Relay)
IG1 40A IG1 Relay, ACC Relay
WIPER FRT2 7.5A
IBU (Integrated Body Control Unit), ECM (Engine Control
Module)/PCM (Power train Control Module)
SENSOR6 20A
[Smartstream D2.2] PM (Particulate Matter) Sensor, Front
Nox Sensor, Rear Nox Sensor
[Smartstream G3.5] ECM (Engine Control Module)/PCM
(Power train Control Module)
SENSOR1 20A
[Smartstream D2.2] Rail Pressure Control Valve
[Smartstream G3.5] Ignition Coil #1/#2/#3/#4/#5/#6
SENSOR8 10A [Smartstream D2.2] Glow Control Unit
ECU2 10A
ECM (Engine Control Module)/PCM (Power train Control
Module)
SENSOR5 10A
Engine Room Junction Block (Fuel Pump Relay)
[Smartstream D2.2] Engine Room Junction Block (Fuel
Heater Relay)
MODULE 7.5A Front Rader Unit
SENSOR9 20A
[Smartstream D2.2] Fuel Metering Valve
[Smartstream G3.5] ECM (Engine Control Module)/PCM
(Power train Control Module)
SENSOR3 20A
ECM (Engine Control Module)/PCM (Power train Control
Module)
SENSOR2 15A
[Smartstream D2.2] Lambda Sensor #1/#2
[Smartstream G3.5] Oxygen Sensor #3
WIPER FRT1 30A Front Wiper Motor
IG2
IG1
2
FRT
S6
S1
S8
E2
S5
MODULE
S9
S3
S2
1
FRT
