81
7
7
Maintenance Fuses
2A
Multifunction Switch, 8iper Motor, Engine 3oom Junction
Block (8iper LO 3elay)
10A
Power Outlet 3elay, BCM (Body Control Module), SLM Unit,
Audio, Audio/Video & Navigation Head Unit, DC-DC Converter,
USB Charging Connector, Power Outside Mirror Switch, Smart
Key Control Module
20A Spare
7.A Instrument Cluster
7.A Instrument Cluster
7.A MDPS (Motor Driven Power Steering) Unit
20A DC-DC Converter, Audio, Audio / Video & Navigation Head Unit
10A
3oom Lamp 3elay, Air Conditioner Control Module, Auto Light
& Photo Sensor, BCM (Body Control Module), Instrument Clus
-
ter, 3ain Sensor, SLM Unit, Glove Box Lamp, Tailgate 3oom
Lamp, 3oom Lamp, Overhead Console Lamp, Front Vanity
Lamp Left Handle Side/3ight Handle Side
SZmbol
Fuse
rating
Circuit Protected
